Tractor · 2005Unverified

Challenger MT275B

Name: Challenger MT275B
Brand: Challenger

Challenger MT275B — MT200B Series · 40 hp. Reference specifications; pending source verification.

The Challenger MT275B is a tractor model with a rating of approximately 40 hp, positioning it at the lower end of its class in terms of power. This model was manufactured from 2005 to 2008. It is equipped with a 3-cylinder turbocharged diesel liquid-cooled engine and four-wheel drive, paired with a hydrostatic transmission. The operating weight of the Challenger MT275B is 1437 kg, with a maximum suitable operating area of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

40 hp

Weight

1437 kg

Catalogue coverage

Variants represented

Richest spec table

118 rows

Recorded power

40 hp

Recorded weight

1437 kg

Transmissions

hydrostatic

Production years

2005-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorChallenger (a part of AGCO)Reference

ManufacturerIsekiReference

Compact Utility tractorReference

Built in Matsuyama, JapanReference

Four-wheel driveReference

Final drivesspur gearReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post foldable ROPSReference

Variants

1540similar Massey Ferguson modelReference

Engine

Iseki 1.5L 3-cyl dieselReference

Engine (gross)29.9 kWReference

Engine (net)28.3 kWReference

Iseki E3CD-VTB10Reference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke87 x 84 mmReference

Power (net)28.3 kWReference

Power (gross)29.9 kWReference

Fuel systemindirect injectionReference

Air cleanerdual-stage dryReference

Pre-heatingglow plugsReference

Compression21.7:1Reference

Rated RPM2600Reference

Idle RPM980-2860Reference

Starter volts12Reference

Oil capacity4.7 LReference

Coolant capacity6.7 LReference

Transmission

hydrostaticReference

8-speedReference

12-speed partially synchronized with power shuttleReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Oil capacity31.0 LReference

TransmissionSynchroShuttleReference

Gears8 forward and reverseReference

Clutchmechanical dry discReference

Four non-synchronized gears in two non-synchronized ranges, with synchronized shuttle shift.Reference

TransmissionPowerShuttleReference

Typepartially synchronized with power shuttleReference

Gears12 forward and reverseReference

Clutchdry main, wet shuttleReference

Three ranges with four gears each. Transmission can be shifted from forward to reverse on the go, without the clutch. In-range gear changes can be made on the go with the clutch.Reference

PTO & Hydraulics

Gear PTO (claimed)23.5 kWReference

Hydro PTO (claimed)22.0 kWReference

Hydraulic system31.0 LReference

Typeopen centerReference

Capacity31.0 LReference

Pressure156.9 barReference

Rear valves2Reference

Mid valves2Reference

Pump flow31.4 lpmReference

Total flow48.1 lpmReference

Total flow51.9 lpmReference

Steering flow16.7 lpmReference

Steering flow20.4 lpmReference

Steering press.156.9 barReference

Rear TypeIReference

Controlposition and response controlReference

Controloptional top-link draft controlReference

Rear lift (at ends)1270 kgReference

Rear lift (at 24"/610mm)1149 kgReference

Rear Armsfixed link ends ((sync shuttle)Reference

Rear Armstelescopic link ends (power shuttle/hydro)Reference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependentReference

Mid PTO Type2000 (1.00)Reference

Capacities

Fuel40.1 LReference

Max capacity3000 kgReference

Dimensions

Wheelbase177 cmReference

Weight1437 kgReference

Front tire8-16Reference

Rear tire12.4-24Reference

Ag front8-16Reference

Ag rear12.4-24Reference

Ag rear13.6-24Reference

Lawn/turf front27x8.50-15Reference

Lawn/turf rear41x14.00-20Reference

Industrial front10-16.5Reference

Industrial rear14.9-24Reference

Length307 cmReference

Width157 cmReference

Height (ROPS)221 cmReference

Ground clearance35 cmReference

Front axle1239 mmReference

Flange rear axle1132 mmReference

Front tread114 cmReference

1437 kgReference

Max front axle1799 kgReference

Max rear axle1799 kgReference

Challenger MT275B attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps40Reference

Battery CCA630Reference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Challenger MH20B Backhoe

Backhoe typeChallenger MH20B BackhoeReference

Transport height190 cmReference

Bucket width25 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width60 cmReference

Bucket width93 cmReference

Digging depth228 cmReference

Reach from pivot284 cmReference

Bucket Rotation165°Reference

Swing Arc180°Reference

Bucket force1474 kgReference

Dipperstick force861 kgReference

Speeds

With 12.4-24 R1 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
