Tractor · 2003Unverified
Challenger MT297
Challenger MT297 — MT200 Series · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
1759 kg
Hover a source tag to verify
Overview
DistributorChallenger (a part of AGCO)Reference
ManufacturerIsekiReference
Compact Utility tractorReference
Original price was $25,500 in 2004Reference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Variants
1455similar Massey Ferguson modelReference
Engine
Iseki 2.8L 4-cyl dieselReference
Fuel tank48.1 LReference
Engine (gross)41.2 kWReference
IsekiReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.8 LReference
Power (gross)41.2 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
16-speed power shuttleReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Clutchdry discReference
Typepower shuttleReference
Gears16 forward and reverseReference
Clutchdry disc (gears)Reference
Clutchwet disc (shuttle)Reference
Four synchronized gears (1-4) in four ranges with power shuttle.Reference
PTO & Hydraulics
PTO (claimed)34.0 kWReference
Typeopen centerReference
Pressure179.3 barReference
Pump flow43.1 lpmReference
Total flow65.5 lpmReference
Steering flow22.3 lpmReference
Rear TypeIReference
Controlposition controlReference
Controldraft controlReference
Rear lift (at ends)1399 kgReference
Rear lift (at 24"/610mm)1179 kgReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type540Reference
Dimensions
Wheelbase187 cmReference
Weight1759 kgReference
Front tire9.5-16Reference
Rear tire13.6-28Reference
Standard tires (ag)Front: 9.5-16. Rear: 13.6-28Reference
Lawn/turf front29x12.00-15Reference
Lawn/turf rear475/65D-20Reference
Lawn/turf front27x12LL-15Reference
Lawn/turf rear570-648Reference
Industrial front10-16.5Reference
Industrial rear17.5-24Reference
Length347 cmReference
Width181 cmReference
Height (ROPS)242 cmReference
Height (Folded ROPS)184 cmReference
Front tread133 cmReference
Rear tread132 to 152 cmReference
Challenger MT297 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Challenger MH20 Backhoe
Backhoe typeChallenger MH20 BackhoeReference
Transport height184 cmReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width60 cmReference
Bucket width93 cmReference
2-Foot flat digging depth243 cmReference
Reach from pivot284 cmReference
Bucket Rotation165°Reference
Swing Arc180°Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
