Tractor · 2006Unverified

Challenger MT345B

Challenger MT345B — MT300B Series · 91 hp. Reference specifications; pending source verification.

The Challenger MT345B is a tractor with a rated output of 91 hp, which positions it in the middle of its class for power. It was manufactured from 2006 to 2010. It features a 3-cylinder turbocharged diesel liquid-cooled engine, coupled with a four-wheel drive system and a 12-speed gearbox. The listed weight varies from 5291 to 7716 pounds, and it is designed for operations on around 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
91 hp
Weight
5291 to 7716 pounds

Catalogue coverage

Variants represented
2
Richest spec table
65 rows
Recorded power
91 hp
Transmissions
12-speed synchronized shuttle
Production years
2006-2010
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorChallenger (a part of AGCO)Reference
ManufacturerAgritaliaReference
Utility tractorReference
Built in Rovigo, ItalyReference
Two- or four-wheel driveReference
Differential lockelectro-hydraulicReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post folding ROPS. Cab with air-conditioning optional.Reference

Variants

3645similar Massey Ferguson modelReference

Engine

SisuDiesel 3.3L 3-cyl dieselReference
Fuel tank109.8 LReference
Engine (gross)67.9 kWReference
SisuDiesel 33 DTAReference
turbocharged aftercooled dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement3.3 LReference
Bore/Stroke108 x 120 mmReference
EmissionsTier IIReference
Power (gross)67.9 kWReference
Fuel systemdirect injectionReference
Compression18.5:1Reference
Rated RPM2150Reference
StarterelectricReference
Starter volts12Reference
Oil capacity10.5 LReference

Transmission

12-speed synchronized shuttleReference
12-speed power shuttleReference
Typesynchronized shuttleReference
Gears12 forward and reverseReference
Four gears in three ranges with mechanical shuttle.Reference
Typepower shuttleReference
Four gears in three ranges with power shuttle. Push-button clutch allows gear shifting without the use of the foot clutch.Reference

PTO & Hydraulics

PTO (claimed)55.9 kWReference
Typeopen centerReference
Pressure190.0 barReference
Rear valves2 or 3Reference
Mid valves2Reference
Pump flow59.8 lpmReference
Total flow84.8 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift (at ends)2494 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/540EReference

Dimensions

Wheelbase210 cmReference
Weight5291 to 7716 poundsReference
Length375 cmReference
Width193 cmReference
Height (ROPS)266 cmReference
Height (cab)260 cmReference
2399 kgReference
2600 kgReference
3499 kgReference

Challenger MT345B attachments

front-end loaderReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps80Reference
Battery CCA675Reference
Battery volts12Reference

Attachment overview

Challenger ML72B loaderReference
Challenger ML92B loaderReference
