Tractor · 2017Unverified
Challenger MT485E
Challenger MT485E — MT400E Series · 132 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
132 hp
Max power
107.4 kW
Weight
6999 kg
Hover a source tag to verify
Overview
ManufacturerChallenger (a part of AGCO)Reference
Utility tractorReference
Built in FranceReference
Four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning. Auto-Guide 3000 ((Optional))Reference
Variants
6715Ssimilar Massey Ferguson modelReference
Engine
AGCO Power 4.9L 4-cyl dieselReference
Fuel tank253.6 LReference
Exhaust fluid (DEF)29.9 LReference
Engine104.4 kWReference
Drawbar (tested)92.9 kWReference
AGCO PowerReference
intercooled turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.9 LReference
Bore/Stroke108 x 134 mmReference
EmissionsTier IVReference
Emission controlselective catalytic reductionReference
Power104.4 kWReference
Maximum Power111.9 kWReference
Fuel systemhigh-pressure common rail direct injectionReference
Rated RPM2100Reference
Torque844.8 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Max power107.4 kWReference
Power at rated engine speed98.7 kWReference
Max power92.9 kWReference
Transmission
16-speed four-speed power shiftReference
24-speed six-speed power shiftReference
continuously-variable transmissionReference
TransmissionAutoPower IVReference
Typefour-speed power shiftReference
Gears16 forward and reverseReference
Clutchhydraulic wet discReference
TransmissionAutoPower VIReference
Typesix-speed power shiftReference
Gears24 forward and reverseReference
TransmissionTechStar CVTReference
Typecontinuously-variable transmissionReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)96.9 kWReference
PTO (tested)107.4 kWReference
Typeopen centerReference
Valvesup to 5Reference
Pump flow98.4 lpmReference
Pump flow109.8 lpmReference
Pump flow189.2 lpmReference
Rear TypeIII/IIReference
Rear lift (at 24"/610mm)5100 kgReference
Rear Armstelescopic link endReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Rear PTO Type540/540E/1000/1000EReference
Power at rated PTO speed104.0 kWReference
Dimensions
Wheelbase266 cmReference
Weight6999 kgReference
Width182 cmReference
Shipping weight6999 kgReference
Flange rear axleReference
Bar rear axleReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps175Reference
Charging amps240Reference
Battery volts12Reference
Test results
Diesel AutoPower IV 4WDOctober 2016 - 2016, Link: OCED Tractor Test 3031 fileReference
PTO performanceReference
Fuel use32.6 l/hourReference
Fuel use31.4 l/hourReference
Drawbar performanceReference
Fuel use32.9 l/hourReference
Gear 3A used for power test.Reference
Max pull5874 kgReference
Gear 1B used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
