Tractor · 2017Unverified
Challenger MT495E
Challenger MT495E — MT400E Series · 138 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
138 hp
Max power
95.5 kW
Weight
6999 kg
Hover a source tag to verify
Overview
ManufacturerChallenger (a part of AGCO)Reference
Utility tractorReference
Built in FranceReference
Four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning. Auto-Guide 3000 ((Optional))Reference
Variants
6716Ssimilar Massey Ferguson modelReference
Engine
AGCO Power 4.9L 4-cyl dieselReference
Fuel tank253.6 LReference
Exhaust fluid (DEF)29.9 LReference
Engine111.9 kWReference
Drawbar (tested)95.5 kWReference
AGCO PowerReference
intercooled turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.9 LReference
Bore/Stroke108 x 134 mmReference
EmissionsTier IVReference
Emission controlselective catalytic reductionReference
Power111.9 kWReference
Maximum Power119.3 kWReference
Fuel systemhigh-pressure common rail direct injectionReference
Rated RPM2100Reference
Torque884.1 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Power at rated engine speed103.2 kWReference
Max power95.5 kWReference
Transmission
24-speed six-speed power shiftReference
continuously-variable transmissionReference
TransmissionAutoPower VIReference
Typesix-speed power shiftReference
Gears24 forward and reverseReference
Clutchhydraulic wet discReference
TransmissionTechStar CVTReference
Typecontinuously-variable transmissionReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)104.4 kWReference
PTO (tested)103.2 kWReference
Typeopen centerReference
Valvesup to 5Reference
Pump flow98.4 lpmReference
Pump flow109.8 lpmReference
Pump flow189.2 lpmReference
Rear TypeIII/IIReference
Rear lift (at 24"/610mm)5100 kgReference
Rear Armstelescopic link endReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Rear PTO Type540/540E/1000/1000EReference
Power at rated PTO speed114.5 kWReference
Dimensions
Wheelbase266 cmReference
Weight6999 kgReference
Width182 cmReference
Shipping weight6999 kgReference
Flange rear axleReference
Bar rear axleReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps175Reference
Charging amps240Reference
Battery volts12Reference
Test results
Diesel CVT 4WDOctober 2016 - November 2016, Link: OCED Tractor Test 3035 fileReference
PTO performanceReference
Fuel use32.2 l/hourReference
Fuel use33.7 l/hourReference
Drawbar performanceReference
Fuel use34.4 l/hourReference
Pull at 7.69KPHReference
Max pull6924 kgReference
Pull at 3.57KPHReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
