Tractor · 2018Unverified
Challenger MT740
Challenger MT740 — MT700 Series · 400 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
400 hp
Max power
261.7 kW
Weight
15169 kg
Hover a source tag to verify
Overview
ManufacturerChallenger (a part of AGCO)Reference
Agricultural Crawler tractorReference
Built in Jackson, Minnesota, USAReference
DrivecrawlerReference
Cab standard with air-conditioning.Reference
Engine
AGCO Power 9.8L 7-cyl dieselReference
Fuel tank681.3 LReference
Fuel tank813.8 LReference
Fuel tank972.7 LReference
Exhaust fluid (DEF)79.5 LReference
Engine (gross)298.3 kWReference
Drawbar (tested)218.5 kWReference
AGCO PowerReference
turbocharged intercooled dieselReference
7-cylinderReference
liquid-cooledReference
Displacement9.8 LReference
Bore/Stroke111 x 145 mmReference
Rated Power (gross)298.3 kWReference
Rated RPM1700Reference
Starter typeelectricReference
Max power261.7 kWReference
Power at rated engine speed257.5 kWReference
Max power218.5 kWReference
Transmission
infinitely-variable transmissionReference
TransmissionAccu-VTReference
Typeinfinitely-variable transmissionReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)231.2 kWReference
PTO (tested)261.7 kWReference
Typeload sensingReference
Valves4 to 6Reference
Pump flow219.5 lpmReference
Pump flow439.1 lpmReference
Rear TypeIII/IVNReference
Rear lift8618 kgReference
Power at rated PTO speed260.6 kWReference
Dimensions
Weight15169 kgReference
TracksReference
Max weight18597 kgReference
Front axleBarReference
Bar rear axleReference
Gauge182 to 223 cmReference
Gauge182 to 304 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Test results
Diesel CVT crawlerOctober 11 - 24, 2018Link: OCED Tractor Test 2206 fileReference
PTO performanceReference
Fuel use70.0 l/hourReference
Fuel use69.6 l/hourReference
Drawbar performanceReference
Pull at 9.83KPHReference
Max pull15441 kgReference
Pull at 3.49KPHReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
