Tractor · 2018Unverified

Challenger MT740

Name: Challenger MT740
Brand: Challenger

Challenger MT740 — MT700 Series · 400 hp. Reference specifications; pending source verification.

The Challenger MT740 is a tractor model rated at approximately 400 hp, which positions it within the higher power range of its class. It was manufactured in 2018. The tractor features a 7-cylinder turbocharged intercooled diesel liquid-cooled engine, combined with a tracked undercarriage and a continuously variable transmission. Its listed operating weight is 15,169 kg, and it is suitable for operations covering 1,500+ acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

400 hp

Max power

261.7 kW

Weight

15169 kg

Catalogue coverage

Variants represented

Richest spec table

54 rows

Recorded power

400 hp

Recorded weight

15169 kg

Production years

2018-2018

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerChallenger (a part of AGCO)Reference

Agricultural Crawler tractorReference

Built in Jackson, Minnesota, USAReference

DrivecrawlerReference

Cab standard with air-conditioning.Reference

Engine

AGCO Power 9.8L 7-cyl dieselReference

Fuel tank681.3 LReference

Fuel tank813.8 LReference

Fuel tank972.7 LReference

Exhaust fluid (DEF)79.5 LReference

Engine (gross)298.3 kWReference

Drawbar (tested)218.5 kWReference

AGCO PowerReference

turbocharged intercooled dieselReference

7-cylinderReference

liquid-cooledReference

Displacement9.8 LReference

Bore/Stroke111 x 145 mmReference

Rated Power (gross)298.3 kWReference

Rated RPM1700Reference

Starter typeelectricReference

Max power261.7 kWReference

Power at rated engine speed257.5 kWReference

Max power218.5 kWReference

Transmission

infinitely-variable transmissionReference

TransmissionAccu-VTReference

Typeinfinitely-variable transmissionReference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

PTO (claimed)231.2 kWReference

PTO (tested)261.7 kWReference

Typeload sensingReference

Valves4 to 6Reference

Pump flow219.5 lpmReference

Pump flow439.1 lpmReference

Rear TypeIII/IVNReference

Rear lift8618 kgReference

Power at rated PTO speed260.6 kWReference

Dimensions

Weight15169 kgReference

TracksReference

Max weight18597 kgReference

Front axleBarReference

Bar rear axleReference

Gauge182 to 223 cmReference

Gauge182 to 304 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Test results

Diesel CVT crawlerOctober 11 - 24, 2018Link: OCED Tractor Test 2206 fileReference

PTO performanceReference

Fuel use70.0 l/hourReference

Fuel use69.6 l/hourReference

Drawbar performanceReference

Pull at 9.83KPHReference

Max pull15441 kgReference

Pull at 3.49KPHReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
