Tractor · 2012Unverified
Challenger MT755D
Challenger MT755D — MT700D Series · 327 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
327 hp
Max power
236.8 kW
Weight
14095 kg
Hover a source tag to verify
Overview
ManufacturerChallenger (a part of AGCO)Reference
Agricultural Crawler tractorReference
Built in Jackson, Minnesota, USAReference
DrivecrawlerReference
Steeringelectro-hydraulic differentialReference
Hydraulic wet disc brakesReference
Cab standard.Reference
Engine
AGCO POWER 8.4L 6-cyl dieselReference
Fuel tank412.6 LReference
Fuel tank639.7 LReference
Exhaust fluid (DEF)68.1 LReference
Engine (gross)243.8 kWReference
Drawbar (tested)187.6 kWReference
AGCO POWERReference
turbocharged air-to-air intercooled dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement8.4 LReference
Bore/Stroke111 x 145 mmReference
EmissionsInterim Tier IVReference
Emission controlselective catalytic reduction (SCR)Reference
Power (gross)243.8 kWReference
Maximum Power269.2 kWReference
Starter volts12Reference
Max power236.8 kWReference
Power at rated engine speed209.8 kWReference
Max power187.6 kWReference
Transmission
16-speed full power shiftReference
TransmissionCaterpillarReference
Typefull power shiftReference
Gears16 forward and 4 reverseReference
Clutchhydraulic wet discReference
PTO & Hydraulics
PTO (claimed)193.9 kWReference
PTO (tested)236.8 kWReference
Typeclosed-center pressure-flow compensated (PFC)Reference
Pressure200.0 barReference
Valves4 to 6Reference
Pump flow164.6 lpmReference
Pump flow223.3 lpmReference
SCV flow136.3 lpmReference
Rear TypeIII/IIINReference
Rear lift7257 kgReference
Rear PTOindependentReference
Rear PTO Type1000 (1.75)Reference
Power at rated PTO speed230.1 kWReference
Dimensions
Weight14095 kgReference
14-inch tracksReference
Gauge182 to 223 cmReference
Gauge203 to 304 cmReference
Gauge304 to 406 cmReference
Shipping14095 kgReference
Max Drawbar4536 kgReference
Max Drawbar5443 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps300 (2x 150amp)Reference
Batteries2Reference
Battery volts12Reference
Challenger MT755D Tracks
Width35 cmReference
Width40 cmReference
Width45 cmReference
Width63 cmReference
Width76 cmReference
Capacities
Max capacity16329 kgReference
Test results
Diesel 16-speed crawlerMay 21 - 30, 2013Link: OCED Tractor Test 2061 fileReference
PTO performanceReference
Fuel use62.1 l/hourReference
Fuel use58.7 l/hourReference
Fuel use62.5 l/hourReference
Drawbar performanceReference
Gear 8 used for power test.Reference
Max pull14069 kgReference
Gear 3 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
