Tractor · 2014Unverified

Challenger MT845E

Name: Challenger MT845E
Brand: Challenger

Challenger MT845E — MT800E Series · 450 hp. Reference specifications; pending source verification.

The Challenger MT845E is a tractor with a power rating of 450 hp, positioning it within the higher-powered machines of its class. Manufactured from 2014 to 2020, this model features a 12-cylinder turbocharged diesel liquid-cooled engine, which powers a tracked undercarriage via a powershift transmission. It has a listed weight of 19,321 kg and is suited for operations on areas of approximately 1,500 acres or more.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

450 hp

Max power

314.4 kW

Weight

19321 kg

Catalogue coverage

Variants represented

Richest spec table

110 rows

Recorded power

450 hp

Recorded weight

19321 kg

Transmissions

16-speed full power shift

Production years

2014-2020

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerChallenger (a part of AGCO)Reference

Agricultural Crawler tractorReference

Built in Jackson, Minnesota, USAReference

DrivecrawlerReference

Steeringpower differentialReference

Cab standard with air-conditioning.Reference

Engine

AGCO Power 16.8L 12-cyl dieselReference

Fuel tank1249.0 LReference

Exhaust fluid (DEF)115.4 LReference

Engine (gross)335.6 kWReference

Drawbar (tested)241.8 kWReference

AGCO PowerReference

turbocharged dieselReference

12-cylinder 48-valveReference

liquid-cooledReference

Displacement16.8 LReference

Bore/Stroke111 x 145 mmReference

EmissionsTier IVReference

Emission controlselective catalytic reduction (SCR)Reference

Power (gross)335.6 kWReference

Maximum Power362.4 kWReference

Rated RPM2100Reference

Torque2175.0 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Max power314.4 kWReference

Power at rated engine speed275.7 kWReference

Max power241.8 kWReference

Fuel TypedieselReference

No of Cylinders12 cylinderReference

Rated engine speed2,100 RPMReference

Emissions complianceTier IV | selective catalytic reduction (SCR)Reference

Engine torque at rated speed727.6 kgReference

Bore and stroke4.370x5.709 inchesReference

Cooling systemliquid-cooledReference

Transmission

16-speed full power shiftReference

TransmissionCaterpillarReference

Typefull power shiftReference

Gears16 forward and 4 reverseReference

Clutchhydraulic wet discReference

Transmission TypePowershiftReference

forward and reverse optionsCaterpillar - 16R and 4RReference

Track Drive type4WDReference

PTO & Hydraulics

PTO (claimed)272.2 kWReference

PTO (tested)314.4 kWReference

Typeclosed center pressure flow compensatedReference

Pressure200.0 barReference

Valves4 to 6Reference

Pump flow219.9 lpmReference

Pump flow321.7 lpmReference

SCV flow99.9 lpmReference

SCV flow136.3 lpmReference

Rear lift8845 kgReference

DrawbarCat. 4Reference

DrawbarCat. 5Reference

Rear PTOindependentReference

ClutchelectronicReference

Rear PTO Type1000 (1.75)Reference

Power at rated PTO speed314.4 kWReference

Dimensions

Weight19321 kgReference

18-inch tracksReference

Front axleBarReference

Bar rear axleReference

Gauge228 to 325 cmReference

Shipping19321 kgReference

Max Drawbar4536 kgReference

Max Drawbar5670 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps300 (2x 150)Reference

Batteries4Reference

Battery CCA1000Reference

Battery volts12Reference

Battery options4Reference

Total cold cranking amps1,000 CCAReference

Challenger MT845E Tracks

Width45 cmReference

Width69 cmReference

Width76 cmReference

Width91 cmReference

Capacities

Max capacity25362 kgReference

Capacity1,027.5 ciReference

Diesel exhaust fluid (DEF) tank115.5 LReference

Test results

Diesel 16-speed crawlerNovember 2 - 7, 2016Link: OCED Tractor Test 2166 fileReference

PTO performanceReference

Fuel use94.2 l/hourReference

Fuel use90.1 l/hourReference

Drawbar performanceReference

Gear 6 used for power test.Reference

Max pull20492 kgReference

Gear 3 used for pull test.Reference

General

Make & ModelChallenger (a part of AGCO)Reference

Drawbar categoryCat. 4, Cat. 5Reference

Front Axle TypeBarReference

Country of manufacturerUSAReference

Hydraulics

Capacity Valves48 valveReference

Hydraulics Typeclosed center pressure flow compensatedReference

Maximum operating pressure2,900 psiReference

Remote Valves4 to 6 valvesReference

Rear Hitch maximum lift capacity8,845 kgReference

Power

Rated Power450 hpReference

PTO

PTO Power365 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Dimensions & weight

Overall weight19,321.2 kgReference

Track width91.4 cmReference

Operator station

Cab AvailabilityTrueReference

Cab Air conditioning, temperature differentialCab standard with air-conditioningReference

Seat SuspensionTRUEReference

Steering & brakes

Steering typepower differentialReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
