Industrial Tractor · 1958Unverified
Chamberlain Champion Mark II
Chamberlain Champion Mark II — Industrial tractor · 62 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
62 hp
Weight
7900 to 12282 pounds
Hover a source tag to verify
Overview
ManufacturerChamberlainReference
Industrial tractorReference
Built in Welshpool, AustraliaReference
Two-wheel driveReference
Final drivesbull gearsReference
Power steeringReference
Drum brakesReference
Open operator station. Steel cab optional.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank74.9 LReference
Engine46.2 kWReference
Drawbar (claimed)33.6 kWReference
Belt (claimed)38.0 kWReference
Perkins 4/270DReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke108 x 121 mmReference
Power46.2 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Rated RPM2000Reference
Torque256.3 NmReference
Torque RPM1000Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
4-speed torque converterReference
4-speed power shiftReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutch355mm discReference
Typetorque converterReference
Gears4 forward and reverseReference
TransmissionBorg Warner T22NReference
Typepower shiftReference
Dimensions
Wheelbase241 cmReference
Weight7900 to 12282 poundsReference
Front tire8.25x20x10Reference
Rear tire15x28x8Reference
Industrial front8.25x20x10Reference
Industrial rear15x28x8Reference
Length358 cmReference
Length510 cmReference
Width233 cmReference
Height (exhaust)236 cmReference
Weight3583 kgReference
Weight5571 kgReference
Front tread161 cmReference
Rear tread187 cmReference
Chamberlain Champion Mark II attachments
front-end loaderReference
Champion Mark II Serial Numbers
1958206Reference
1959318Reference
1960674Reference
19611080Reference
19621267Reference
19631544Reference
19641967Reference
19652492Reference
19663148Reference
19673739Reference
19684276Reference
19694852Reference
Final4917Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemgeneratorReference
Batteries2Reference
Battery volts6Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
