Industrial Tractor · 1969Unverified
Chamberlain Contractor 354
Chamberlain Contractor 354 — Industrial tractor · 91 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
91 hp
Weight
4232 kg
Hover a source tag to verify
Overview
ManufacturerChamberlainReference
Industrial tractorReference
Built in Welshpool, AustraliaReference
Two-wheel driveReference
Final drivesspur gearReference
Manual steeringReference
Mechanical shoe brakesReference
Open operator station.Reference
Engine
Perkins 5.8L 6-cyl dieselReference
Fuel tank204.4 LReference
Engine75.3 kWReference
Perkins 6-354Reference
dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement5.8 LReference
Bore/Stroke98 x 127 mmReference
Power75.3 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Pre-heatingthermostartReference
Compression16:1Reference
Rated RPM2200Reference
Torque359.3 NmReference
Torque RPM1300Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speed gearReference
TypegearReference
Gears9 forward and 3 reverseReference
Clutch355.6mm dry discReference
Three gears, plus reverse, in three ranges.Reference
PTO & Hydraulics
PTO (claimed)67.9 kWReference
Dimensions
Wheelbase260 cmReference
Weight4232 kgReference
Front tire9.00-20Reference
Rear tire22.50-26Reference
Industrial front9.00-20Reference
Industrial rear22.50-26Reference
Length393 cmReference
Ballasted weight5493 kgReference
Clearance (front axle)46 cmReference
Front tread162 cmReference
Rear tread187 cmReference
Steering wheel192 cmReference
Contractor 354 Serial Numbers
19691001Reference
19701010Reference
19711024Reference
19721033Reference
19731048Reference
19741060Reference
19751074Reference
Final1083Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemalternatorReference
Batteries2Reference
Battery volts6Reference
Chamberlain Contractor 354 Height
Hood165 cmReference
Exhaust247 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
