Tractor · 1958Unverified
Chamberlain Countryman
Chamberlain Countryman — Countryman Series · 76 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
76 hp
Weight
4082 kg
Hover a source tag to verify
Overview
ManufacturerChamberlainReference
Standard-tread tractorReference
Built in Welshpool, AustraliaReference
Two-wheel driveReference
Internal expanding brakesReference
Open operator station.Reference
Variants
MkI1958-1959Reference
MkII1960Reference
MkIII1961-1962Reference
Engine
Meadows 5.4L 4-cyl dieselReference
Fuel tank106.7 LReference
Engine56.7 kWReference
Drawbar (claimed)44.7 kWReference
Belt (claimed)50.0 kWReference
Meadows 4DC330Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement5.4 LReference
Bore/Stroke120 x 120 mmReference
Power56.7 kWReference
Compression16:1Reference
Rated RPM1800Reference
Starter volts12Reference
Transmission
9-speed gearReference
TypegearReference
Gears9 forward and 3 reverseReference
Clutch355.6mm dry discReference
Three gears, plus reverse, in three ranges.Reference
PTO & Hydraulics
Total flow29.1 lpmReference
Rear PTOindepenentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1600Reference
Dimensions
Wheelbase219 cmReference
Weight4082 kgReference
Front tire8.25x20Reference
Rear tire15x30Reference
Ag front8.25x20Reference
Ag rear15x30Reference
Length370 cmReference
Width223 cmReference
Height (steering wheel)179 cmReference
Ground clearance45 cmReference
Countryman Serial Numbers
1958101Reference
19591158Reference
19601344Reference
19611407 (Mk 3)Reference
19611609 (Mk 3)Reference
19621828 (Mk 3)Reference
Final2003 (Mk 3)Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter26 cmReference
Width15 cmReference
Speed944.88 meters/minReference
Speeds
With 15x30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
