Tractor · 2012Unverified
Chery RA2104
Chery RA2104 — RA Series · 210 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
210 hp
Weight
6500 kg
Hover a source tag to verify
Overview
ManufacturerCheryReference
Row-Crop tractorReference
Built in ChinaReference
Four-wheel driveReference
Differential lockrear standardReference
Steeringhydraulic powerReference
Pneumatic brakes optional brakesReference
Cab standard with air-conditioning.Reference
Engine
Weichai-Deutz 6.9L 6-cyl dieselReference
Engine (gross)156.6 kWReference
Weichai-Deutz WP6T210E200Reference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.9 LReference
Bore/Stroke105 x 132 mmReference
Power (gross)156.6 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
40-speed partial power shiftReference
Typepartial power shiftReference
Gears40 forward and reverseReference
Clutchelectro-hydraulic wet discReference
PTO & Hydraulics
Controlposition, float, and electronic draft controlReference
Rear lift (at 24"/610mm)4527 kgReference
Drawbarswinging drawbarReference
Rear PTOliveReference
Rear PTO Type540/540E/1000/1000EReference
Rear PTO Type760-1000 (optional)Reference
Dimensions
Wheelbase294 cmReference
Weight6500 kgReference
Front tire16.9-30Reference
Rear tire20.8-38 (duals)Reference
Standard tires (ag)Front: 16.9-30. Rear: 20.8-38 (duals)Reference
Length575 cmReference
Width325 cmReference
Height (cab)321 cmReference
Ground clearance36 cmReference
Front tread190 to 203 cmReference
Rear tread283 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
