Tractor · 2012Unverified
Chery RD350
Chery RD350 — RD Series · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
1435 kg
Hover a source tag to verify
Overview
ManufacturerCheryReference
Compact Utility tractorReference
Built in ChinaReference
Two-wheel driveReference
Differential lockmechanical rearReference
Steeringhydraulic powerReference
Pneumatic brake optional brakesReference
Open operator station. Optional two-post ROPS and canopy.Reference
Variants
RD3502WDReference
RD3544WDReference
Engine
Jiang Dong 2.8L 3-cyl dieselReference
Lai Dong 2.2L 4-cyl dieselReference
Engine (gross)26.1 kWReference
Jiang Dong TY3100ITReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.8 LReference
Bore/Stroke100 x 117 mmReference
Power (gross)26.1 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Rated RPM2350Reference
Torque124.1 NmReference
Torque RPM1650Reference
StarterelectricReference
Starter volts12Reference
Lai Dong 4L22BTReference
4-cylinderReference
Displacement2.2 LReference
Bore/Stroke85 x 95 mmReference
Starter typeelectricReference
Transmission
8-speed gearReference
8-speed shuttleReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutch203.2mm dry discReference
TypeshuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)23.1 kWReference
Controlposition and float controlReference
Rear lift (at 24"/610mm)591 kgReference
Drawbarfixed drawbarReference
Drawbarswinging drawbar optionalReference
Rear PTOliveReference
Rear PTO Type540/720Reference
Rear PTO Type540/1000 (optional)Reference
Dimensions
Wheelbase177 cmReference
Weight1435 kgReference
Front tire6.0-16Reference
Rear tire11.2-24Reference
Standard tires (ag)Front: 6.0-16. Rear: 11.2-24Reference
Length335 cmReference
Width152 cmReference
Height204 cmReference
Ground clearance31 cmReference
Front tread109/119/130 cmReference
Rear tread96 to 146 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
