Tractor · 2012Unverified
Chery RD354
Chery RD354 — RD Series · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
1435 kg
Hover a source tag to verify
Overview
ManufacturerCheryReference
Compact Utility tractorReference
Built in ChinaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Steeringhydraulic powerReference
Pneumatic brake optional brakesReference
Open operator station. Optional two-post ROPS and canopy.Reference
Variants
RD3502WDReference
RD3544WDReference
Engine
Jiang Dong 2.8L 3-cyl dieselReference
Lai Dong 2.2L 4-cyl dieselReference
Engine (gross)26.1 kWReference
Jiang Dong TY3100ITReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.8 LReference
Bore/Stroke100 x 117 mmReference
Power (gross)26.1 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Rated RPM2350Reference
Torque124.1 NmReference
Torque RPM1650Reference
StarterelectricReference
Starter volts12Reference
Lai Dong 4L22BTReference
4-cylinderReference
Displacement2.2 LReference
Bore/Stroke85 x 95 mmReference
Starter typeelectricReference
Transmission
8-speed gearReference
8-speed shuttleReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutch203.2mm dry discReference
TypeshuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)23.1 kWReference
Controlposition and float controlReference
Rear lift (at 24"/610mm)591 kgReference
Drawbarfixed drawbarReference
Drawbarswinging drawbar optionalReference
Rear PTOliveReference
Rear PTO Type540/720Reference
Rear PTO Type540/1000 (optional)Reference
Dimensions
Wheelbase178 cmReference
Weight1435 kgReference
Front tire6.5-16Reference
Rear tire11.2-24Reference
Standard tires (ag)Front: 6.5-16. Rear: 11.2-24Reference
Optional tires (ag)Front: 6.5-16. Rear: 9.5-24Reference
Length331 cmReference
Width152 cmReference
Height255 cmReference
Ground clearance28 cmReference
Front tread121 cmReference
Rear tread96 to 146 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
