Tractor · 2012Unverified
Chery RF404
Chery RF404 — RF Series · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
1399 kg
Hover a source tag to verify
Overview
ManufacturerCheryReference
Compact Utility tractorReference
Built in ChinaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Steeringhydraulic powerReference
Pneumatic brakes optional brakesReference
Open operator station. Optional ROPS and canopy.Reference
Variants
RF4002WDReference
RF4044WDReference
Engine
Changchai 2.5L 4-cyl dieselReference
Engine (gross)29.8 kWReference
Changchai ZN490BTReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke90 x 100 mmReference
Power (gross)29.8 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Rated RPM2400Reference
Torque138.0 NmReference
Torque RPM1800Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed sliding gearReference
Typesliding gearReference
Gears8 forward and 2 reverseReference
Clutch203mm dry discReference
PTO & Hydraulics
PTO (claimed)26.5 kWReference
Controlposition and float controlReference
Rear lift (at 24"/610mm)678 kgReference
Drawbarfixed drawbarReference
Drawbarswinging drawbar optionalReference
Rear PTOtransmissionReference
Rear PTO Type540/730Reference
Rear PTO Type540/1000 (optional)Reference
Dimensions
Wheelbase181 cmReference
Weight1399 kgReference
Front tire7.50-16Reference
Rear tire12.4-24Reference
Standard tires (ag)Front: 7.50-16. Rear: 12.4-24Reference
Length331 cmReference
Width154 cmReference
Height255 cmReference
Ground clearance33 cmReference
Front tread109/119/130 cmReference
Rear tread96 to 146 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
