Tractor · 2012Unverified

Chery RK504 Orchard

Name: Chery RK504 Orchard
Brand: Chery

Chery RK504 Orchard — RK Series · 50 hp. Reference specifications; pending source verification.

The Chery RK504 Orchard is a compact tractor with a rated output of 50 hp. It was manufactured in 2012 and features a 4-cylinder diesel liquid-cooled engine. The tractor's drivetrain comprises four-wheel drive and a 12-speed gearbox, and it has a listed weight of 2014 kg. Its maximum working capacity is approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

50 hp

Weight

2014 kg

Catalogue coverage

Variants represented

Richest spec table

58 rows

Recorded power

50 hp

Recorded weight

2014 kg

Transmissions

12-speed shuttle

Production years

2012-2012

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCheryReference

Orchard/Vineyard tractorReference

Built in ChinaReference

Four-wheel driveReference

Differential lockmechanical rearReference

Steeringhydraulic powerReference

Pneumatic brake optional brakesReference

Open operator station. Optional ROPS. Optional canopy. Cab available with optional air-conditioning.Reference

Variants

RK5002WDReference

RK5044WDReference

RK504 Orchardlow-profileReference

Engine

Xin Chai 3.2L 4-cyl dieselReference

Quanchai 3.2L 4-cyl dieselReference

Engine (gross)37.3 kWReference

Xin Chai 498BTReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.2 LReference

Bore/Stroke98 x 105 mmReference

Power (gross)37.3 kWReference

Fuel systemdirect injectionReference

Air cleaneroil bathReference

Rated RPM2400Reference

Torque122.0 NmReference

Torque RPM1650Reference

StarterelectricReference

Starter volts12Reference

Quanchai QC498Reference

Starter typeelectricReference

Transmission

12-speed shuttleReference

8-speed gearReference

TypeshuttleReference

Gears12 forward and reverseReference

Clutch254mm dry discReference

TypegearReference

Gears8 forward and 4 reverseReference

PTO & Hydraulics

PTO (claimed)31.7 kWReference

Controlposition, draft, and float controlReference

Rear lift (at 24"/610mm)866 kgReference

Drawbarfixed drawbarReference

Drawbarswinging drawbar optionalReference

Rear PTOliveReference

Rear PTO Type540/760Reference

Rear PTO Type540/1000 (optional)Reference

Dimensions

Wheelbase199 cmReference

Weight2014 kgReference

Front tire8.0-18Reference

Rear tire12.4-24Reference

Standard tires (ag)Front: 8.0-18. Rear: 12.4-24Reference

Length398 cmReference

Width165 cmReference

Height169 cmReference

Ground clearance32 cmReference

Front tread124 cmReference

Rear tread130 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
