Tractor · 2012Unverified
Chery RS1054
Chery RS1054 — RS Series · 105 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
105 hp
Weight
3800 kg
Hover a source tag to verify
Overview
ManufacturerCheryReference
Row-Crop tractorReference
Built in ChinaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Steeringhydraulic powerReference
Pneumatic brake optional brakesReference
Cab standard. Available heat and air-conditioning.Reference
Variants
RS10544-cyl turboReference
RS1054F6-cyl naturalReference
Engine
YTO 5.6L 4-cyl dieselReference
Quanchai dieselReference
Engine (gross)78.3 kWReference
YTO LR4V5-23Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement5.6 LReference
Bore/Stroke115 x 135 mmReference
Power (gross)78.3 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Rated RPM2300Reference
Torque400.0 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Quanchai QC4118Reference
Starter typeelectricReference
Transmission
16-speed shuttleReference
TypeshuttleReference
Gears16 forward and 8 reverseReference
Clutch304.8mm dry discReference
PTO & Hydraulics
PTO (claimed)65.6 kWReference
Controlposition and float controlReference
Rear lift (at 24"/610mm)2243 kgReference
Drawbarfixed drawbarReference
Drawbarswinging drawbar optionalReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Rear PTO Type760/1000 (optional)Reference
Dimensions
Wheelbase236 cmReference
Weight3800 kgReference
Front tire13.6-24Reference
Rear tire18.4-34Reference
Standard tires (ag)Front: 13.6-24. Rear: 18.4-34Reference
Length483 cmReference
Width228 cmReference
Height (cab)297 cmReference
Ground clearance41 cmReference
Front tread180/187/189/200 cmReference
Rear tread181 to 241 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
