The Chery RS1054F is a tractor model with a rated power output of 105 horsepower, positioned in the mid-range of its class. It was manufactured in 2012 and features a 4-cylinder turbocharged diesel liquid-cooled engine, coupled with four-wheel drive and a 16-speed gearbox. The vehicle's listed operating weight is 5161 kilograms, and it is suited to operations spanning between 200 and 800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
105 hp
Weight
5161 kg
Catalogue coverage
Variants represented
2
Richest spec table
48 rows
Recorded power
105 hp
Recorded weight
5161 kg
Transmissions
16-speed shuttle
Production years
2012-2012
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerCheryReference
Row-Crop tractorReference
Built in ChinaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Steeringhydraulic powerReference
Pneumatic brake optional brakesReference
Cab standard. Available heat and air-conditioning.Reference
Variants
RS10544-cyl turboReference
RS1054F6-cyl naturalReference
Engine
YTO 6-cyl dieselReference
Engine (gross)78.3 kWReference
YTO LR6A3-23Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Power (gross)78.3 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Rated RPM2300Reference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed shuttleReference
TypeshuttleReference
Gears16 forward and 8 reverseReference
Clutch304.8mm dry discReference
PTO & Hydraulics
PTO (claimed)65.6 kWReference
Controlposition and float controlReference
Rear lift (at 24"/610mm)2243 kgReference
Drawbarfixed drawbarReference
Drawbarswinging drawbar optionalReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Rear PTO Type760/1000 (optional)Reference
Dimensions
Wheelbase258 cmReference
Weight5161 kgReference
Front tire13.6-24Reference
Rear tire18.4-34Reference
Standard tires (ag)Front: 13.6-24. Rear: 18.4-34Reference
Length504 cmReference
Width226 cmReference
Height (cab)299 cmReference
Ground clearance46 cmReference
Front tread191 to 215 cmReference
Rear tread181 to 217 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
