The Chery RS1304F is a high-powered tractor with a rating of 130 hp, positioning it among the more powerful machines in its class. Manufactured in 2012, this model features a 6-cylinder diesel liquid-cooled engine driving through a four-wheel drive system with a 16-speed gearbox. The tractor's listed weight is 5161 kg, and it is designed for use on tracts of land ranging from 200–800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
130 hp
Weight
5161 kg
Catalogue coverage
Variants represented
2
Richest spec table
49 rows
Recorded power
130 hp
Recorded weight
5161 kg
Transmissions
16-speed shuttle
Production years
2012-2012
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerCheryReference
Row-Crop tractorReference
Built in ChinaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Steeringhydraulic powerReference
Pneumatic brake optional brakesReference
Cab standard. Available heat and air-conditioning.Reference
Engine
YTO 6-cyl dieselReference
Quanchai dieselReference
Engine (gross)96.9 kWReference
YTO LR6M5-23Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Power (gross)96.9 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Rated RPM2400Reference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Quanchai QC6108Reference
Starter typeelectricReference
Transmission
16-speed shuttleReference
TypeshuttleReference
Gears16 forward and 8 reverseReference
Clutch304.8mm dry discReference
PTO & Hydraulics
PTO (claimed)81.3 kWReference
Controlposition and float controlReference
Rear lift (at 24"/610mm)2345 kgReference
Drawbarfixed drawbarReference
Drawbarswinging drawbar optionalReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Rear PTO Type760/1000 (optional)Reference
Dimensions
Wheelbase258 cmReference
Weight5161 kgReference
Front tire13.6-24Reference
Rear tire18.4-34Reference
Standard tires (ag)Front: 13.6-24. Rear: 18.4-34Reference
Length504 cmReference
Width226 cmReference
Height (cab)299 cmReference
Ground clearance1193 cmReference
Front tread191 to 215 cmReference
Rear tread181 to 217 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
