Tractor · 2012Unverified
Chery RX180-B
Chery RX180-B — RX Series · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
760 kg
Hover a source tag to verify
Overview
ManufacturerCheryReference
Compact Utility tractorReference
Built in ChinaReference
Two-wheel driveReference
Open operator station. Available two-post ROPS and canopy.Reference
Engine
De Li 1.0L 1-cyl dieselReference
Engine (gross)13.4 kWReference
De Li DLH1105Reference
dieselReference
1-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke105 x 115 mmReference
Power (gross)13.4 kWReference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)11.3 kWReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase137 cmReference
Weight760 kgReference
Front tire4.00-14Reference
Rear tire7.50-20Reference
Standard tires (ag)Front: 4.00-14. Rear: 7.50-20Reference
Length260 cmReference
Width118 cmReference
Height168 cmReference
Ground clearance24 cmReference
Front tread96 cmReference
Rear tread98 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
