Tractor · 2012Unverified
Chery RX300
Chery RX300 — RX Series · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
1060 kg
Hover a source tag to verify
Overview
ManufacturerCheryReference
Compact Utility tractorReference
Built in ChinaReference
Two-wheel driveReference
Open operator station. Available two-post ROPS and canopy.Reference
Variants
RX3002WDReference
RX3044WDReference
Engine
Jiang Dong 1.7L 2-cyl dieselReference
Engine (gross)22.4 kWReference
Jiang Dong JD2102TReference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.7 LReference
Bore/Stroke102 x 105 mmReference
Power (gross)22.4 kWReference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)18.7 kWReference
Rear PTO Type720Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase154 cmReference
Weight1060 kgReference
Front tire5.00-16Reference
Rear tire9.50-24Reference
Standard tires (ag)Front: 5.00-16. Rear: 9.50-24Reference
Length287 cmReference
Width130 cmReference
Height189 cmReference
Ground clearance32 cmReference
Front tread96 cmReference
Rear tread94 to 113 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
