Tractor · 2012Unverified
Chery RX354
Chery RX354 — RX Series · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
1180 kg
Hover a source tag to verify
Overview
ManufacturerCheryReference
Compact Utility tractorReference
Built in ChinaReference
Four-wheel driveReference
Open operator station. Available two-post ROPS and canopy.Reference
Variants
RX3502WDReference
RX3544WDReference
Engine
Lai Dong 2.2L 4-cyl dieselReference
Engine (gross)26.1 kWReference
Lai Dong 4L22BTReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke85 x 95 mmReference
Power (gross)26.1 kWReference
Rated RPM2350Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)24.5 kWReference
Rear PTO Type720Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase160 cmReference
Weight1180 kgReference
Front tire6.00-16Reference
Rear tire9.50-24Reference
Standard tires (ag)Front: 6.00-16. Rear: 9.50-24Reference
Length277 cmReference
Width144 cmReference
Height143 cmReference
Ground clearance31 cmReference
Front tread100 cmReference
Front tread97/119/130 cmReference
Rear tread100/109/119/130 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
