Tractor · 2002Unverified

Claas Ares 826

Name: Claas Ares 826
Brand: Claas

Claas Ares 826 — Ares Series · 181 hp. Reference specifications; pending source verification.

The Claas Ares 826 is a tractor with a rated power of 181 hp, positioning it at the higher end of the power spectrum within its class. The model was produced during the years 2002 and 2003. It features a 6-cylinder turbocharged intercooled engine, coupled with four-wheel drive and a hydrostatic transmission. The tractor has an operating weight of 6556 kg, making it suitable for operations covering an area of 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

181 hp

Weight

6556 kg

Catalogue coverage

Variants represented

Richest spec table

30 rows

Recorded power

181 hp

Recorded weight

6556 kg

Transmissions

32-speed

Production years

2002-2003

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerClaasReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

standard with A/CReference

Engine

6.8L 6-cylReference

Fuel tank275.2 LReference

Engine135.0 kWReference

DPS 6068 HRTReference

intercooled turboReference

6-cylinderReference

Displacement6.8 LReference

Bore/Stroke107 x 127 mmReference

Power135.0 kWReference

Rated RPM2000Reference

Torque759.1 NmReference

Torque RPM1400Reference

Transmission

32-speedReference

Gears32 forward and reverseReference

PTO & Hydraulics

Total flow110.1 lpmReference

Rear lift11332 kgReference

Rear PTO Type540/750/1000Reference

Dimensions

Wheelbase288 cmReference

Weight6556 kgReference

Front tire16.9R28Reference

Rear tire20.8R38Reference

Ag front16.9R28Reference

Ag rear20.8R38Reference

Length453 cmReference

Height303 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
