Tractor · 2014Unverified
Claas Arion 460
Claas Arion 460 — Arion Series · 139 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
139 hp
Weight
5098 kg
Hover a source tag to verify
Overview
ManufacturerClaasReference
Row-Crop tractorReference
Four-wheel driveReference
Differential lockelectro-hydraulicReference
Cab standard. Air-conditioning optional.Reference
Engine
FPT 4.5L 4-cyl dieselReference
Fuel tank190.0 LReference
Exhaust fluid (DEF)22.0 LReference
Engine (gross)103.7 kWReference
Engine (max)104.4 kWReference
FPTReference
turbocharged intercooled dieselReference
4-cylinder 16-valveReference
liquid-cooledReference
Displacement4.5 LReference
EmissionsStage IVReference
Emission controldiesel oxidation catalyist with selective catalytic reduction (SCR) (DOC)Reference
Rated Power (gross)103.7 kWReference
Rated Power (gross)100.7 kWReference
Maximum Power (gross)104.4 kWReference
Fuel systemcommon railReference
Rated RPM2200Reference
Torque570.1 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Oil change600 hReference
Transmission
16-speed four-speed power shiftReference
TransmissionQuadrishiftReference
Typefour-speed power shiftReference
Gears16 forward and reverseReference
Four power shift gears (1-4) in four hydraulically shifted ranges (A-D) with power shuttle. Optional Quadractiv automatic shifting.Reference
PTO & Hydraulics
Typeopen centerReference
Typeclosed center load-sensingReference
Pressure190.0 barReference
Valves2 to 4Reference
Pump flow60.0 lpmReference
Pump flow98.0 lpmReference
Pump flow110.1 lpmReference
Rear TypeIIIReference
Rear lift (at ends)4199 kgReference
Front lift2800 kgReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type540/540EReference
Rear PTO Type540/540E/1000Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
Wheelbase252 cmReference
Weight5098 kgReference
Front tire14.9R28Reference
Rear tire18.4R38Reference
Standard tires (ag)Front: 14.9R28. Rear: 18.4R38Reference
Length444 cmReference
Height (cab)276 cmReference
Max weight8500 kgReference
Clearance (front axle)50 cmReference
Clearance (rear axle)49 cmReference
Front axleProactive suspensionReference
Front tread183 to 0 cmReference
Claas Arion 460 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
