Tractor · 2007Unverified

Claas Arion 640

Name: Claas Arion 640
Brand: Claas

Claas Arion 640 — Model year 2007-20112012-2017 · 155 hp. Reference specifications; pending source verification.

The Claas Arion 640 is a tractor rated at 155 hp, positioning it at the more powerful end of its class. It was produced from 2007 to 2017 and features a 6-cylinder turbocharged intercooled diesel liquid-cooled engine. The Arion 640 is equipped with four-wheel drive and a powershift transmission, and has an operating weight of 6259 kg. It is suitable for operations of 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

155 hp

Max power

177 hp

Weight

6259 kg

Catalogue coverage

Variants represented

Richest spec table

77 rows

Recorded power

155 hp

Recorded weight

6259 kg

Transmissions

24-speed partial power shift with power shuttle

Production years

2007-2017

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerClaasReference

Row-Crop tractorReference

Four-wheel driveReference

Power steeringReference

Trailer brakespneumaticReference

Cab standard with air-conditioning.Reference

Engine

John Deere 6.8L 6-cyl dieselReference

Fuel tank330.1 LReference

Engine115.6 kWReference

John DeereReference

turbocharged intercooled dieselReference

6-cylinder 24-valveReference

liquid-cooledReference

Displacement6.8 LReference

EmissionsTier 3Reference

Power115.6 kWReference

Rated RPM2200Reference

Torque657.1 NmReference

Torque RPM1650Reference

Starter typeelectricReference

Oil change500 hReference

Fuel TypedieselReference

No of Cylinders6 cylinderReference

Rated engine speed2,200 RPMReference

Emissions complianceTier 3Reference

Engine torque at rated speed239 kgReference

Bore and stroke4.19x5.00 inchesReference

Cooling systemliquid-cooledReference

Interval for engine oil change500 hrReference

Transmission

24-speed partial power shift with power shuttleReference

TransmissionHexashiftReference

Typepartial power shift with power shuttleReference

Gears24 forward and reverseReference

Transmission TypePowershiftReference

forward and reverse optionssix-speed power shift - 24 F and 24 RReference

Wheel Drive4WDReference

Clutchwet discReference

PTO & Hydraulics

Typeload sensingReference

Pressure200.0 barReference

Valves2 to 6Reference

Total flow110.1 lpmReference

Rear PTO Type540/1000Reference

Rear PTO Type540/540E/1000/1000E (optional)Reference

Dimensions

Wheelbase281 cmReference

Weight6259 kgReference

Front tire16.9R28Reference

Rear tire20.8R38Reference

Ag front16.9R28Reference

Ag rear20.8R38Reference

Length515 cmReference

Height (cab)300 cmReference

Ground clearance50 cmReference

Operating6259 kgReference

Ballasted7213 kgReference

Capacities

Max capacity9248 kgReference

Max capacity10999 kgReference

Capacity414 ciReference

General

Make & ModelClaasReference

Differential lockelectro-hydraulicReference

Power

Max Power177 hpReference

Rated Power169 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Front PTO PowerAvailableReference

Steering & brakes

BrakesHydraulic wet discReference

Steering typePower SteeringReference

Hydraulics

Pump Rated Output (total)29.1 gpmReference

Hydraulics Typeload sensingReference

Maximum operating pressure2,901 psiReference

Remote Valves2 to 6 ValvesReference

Rear Hitch category (SAE designation)Category IIIReference

Dimensions & weight

Overall Height302 cmReference

Overall Length476 cmReference

Front axle clearance49.5 cmReference

Overall weight6,820.2 kgReference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
