Tractor · 2006Unverified

Claas Axion 840

Name: Claas Axion 840
Brand: Claas

Claas Axion 840 — Model year 2006-20132013-2023 · 213 hp. Reference specifications; pending source verification.

The Claas Axion 840 is a tractor with a power rating of 213 hp, placing it at the higher end of its class. It was produced from 2006 to 2023. The tractor features a 6-cylinder turbocharged intercooled diesel liquid-cooled engine and four-wheel drive with a 24-speed gearbox. Its listed operating weight is 7416 kg, suitable for cultivating areas of approximately 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

213 hp

Max power

245 hp

Weight

7416 kg

Catalogue coverage

Variants represented

Richest spec table

56 rows

Recorded power

213 hp

Recorded weight

7416 kg

Transmissions

24-speed

Production years

2006-2023

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerClaasReference

Row-Crop tractorReference

Four-wheel driveReference

cab with A/CReference

Engine

DPS 6.8L 6-cyl dieselReference

Fuel tank406.9 LReference

Engine158.8 kWReference

DPSReference

intercooled turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.8 LReference

Power158.8 kWReference

Rated RPM2200Reference

Torque905.1 NmReference

Torque RPM1500Reference

Fuel TypeDieselReference

Rated engine speed2,150 rpmReference

Cooling systemVisctronic fanReference

Transmission

24-speedReference

Gears24 forward and reverseReference

Transmission TypeCVTReference

Wheel Drive4WDReference

PTO & Hydraulics

TypePFCReference

Pressure200.0 barReference

Valves3 to 5Reference

Total flow110.0 lpmReference

Rear lift9675 kgReference

Front lift3299 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Rear PTO Type540/540E/1000Reference

Front PTOoptionalReference

Front PTO Type1000Reference

Dimensions

Wheelbase298 cmReference

Weight7416 kgReference

Front tire480/70R30Reference

Rear tire620/70R42Reference

Ag front480/70R30Reference

Ag rear620/70R42Reference

Length566 cmReference

Height320 cmReference

Ground clearance58 cmReference

Capacities

Capacity6.7 LReference

Diesel exhaust fluid (DEF) tank41.6 LReference

Power

Max Power245 hpReference

Rated Power230 hpReference

PTO

PTO Power225 hpReference

Front PTO PowerAvailableReference

General

Cruise controlAvailableReference

Precision AgricultureAvailable (Remote diagnostics)\\nAvailable (Telematic)Reference

Hydraulics

Pump Rated Output (total)151.4 l/minReference

Rear Hitch maximum lift capacity9,729.5 kgReference

Front Hitch lift capacity beyond lift points4,590.4 kgReference

Dimensions & weight

Overall weight9,640.6 kgReference

Operator station

Cab AvailabilitytrueReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
