Tractor · 2006Unverified
Claas Axion 850
Claas Axion 850 — Model year 2006-20132013-2023 · 233 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
233 hp
Weight
8096 kg
Hover a source tag to verify
Overview
ManufacturerClaasReference
Row-Crop tractorReference
Four-wheel driveReference
Cab standard with air-conditioning.Reference
Engine
John Deere 6.8L 6-cyl dieselReference
Fuel tank503.0 LReference
Engine173.4 kWReference
John DeereReference
turbocharged intercooled dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement6.8 LReference
EmissionsTier 3Reference
Power173.4 kWReference
Rated RPM2200Reference
Torque1020.1 NmReference
Torque RPM1500Reference
Oil change500 hReference
Transmission
24-speed partial power shift with power shuttleReference
TransmissionHexashiftReference
Typepartial power shift with power shuttleReference
Gears24 forward and reverseReference
PTO & Hydraulics
Typeload sensingReference
Pressure200.0 barReference
Valves3 to 8Reference
Total flow110.1 lpmReference
Total flow149.9 lpmReference
Rear PTO Type540/1000Reference
Rear PTO Type540/540E/1000Reference
Front PTOoptionalReference
Front PTO Type1000Reference
Dimensions
Wheelbase298 cmReference
Weight8096 kgReference
Front tire480/70R30Reference
Rear tire620/70R42Reference
Ag front480/70R30Reference
Ag rear620/70R42Reference
Length572 cmReference
Height (cab)320 cmReference
Ground clearance56 cmReference
Operating8096 kgReference
Ballasted9802 kgReference
Capacities
Max capacity12002 kgReference
Max capacity13998 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
