Tractor · 2008Unverified
Claas Axos 310 CX
Claas Axos 310 CX — Axos Series · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Hover a source tag to verify
Overview
ManufacturerClaasReference
Utility tractorReference
Built in Le Mans, FranceReference
Four-wheel driveReference
High-profile cab standard (low-profile optional) with heat and opening rear window. Optional air-conditioning, radio, opening front window, and sunroof. ROPS optional.Reference
Variants
310Cbase modelReference
10CLdeluxeReference
310CXpremiumReference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank145.0 LReference
Engine55.9 kWReference
Perkins 1104D-44TAReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
EmissionsTier 3Reference
Power55.9 kWReference
Rated RPM2200Reference
Torque307.0 NmReference
Torque RPM1500Reference
Oil change500 hReference
Transmission
20-speed partial power shift with power shuttleReference
30-speedReference
TransmissionTwinshift RevershiftReference
Typepartial power shift with power shuttleReference
Gears20 forward and reverseReference
Adds creeper range to standard transmission. Clutchless reverser for direction changes. Declutching button on gearstick. Two-range power shift.Reference
TransmissionTwinshift Revershift with creeperReference
Gears30 forward and reverseReference
PTO & Hydraulics
Valvesup to 3Reference
Total flow60.2 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)2899 kgReference
Front HitchoptionalReference
Front lift2800 kgReference
Rear PTO Type540/1000Reference
Rear PTO Type540/540E (optional)Reference
Rear PTO Type540/540E/1000 (optional)Reference
Front PTOoptionalReference
Front PTO Type1000Reference
Dimensions
Wheelbase248 cmReference
Front tire11.2R24Reference
Rear tire16.9R30Reference
Ag front11.2R24Reference
Ag rear16.9R30Reference
Length418 cmReference
Ground clearance39 cmReference
Ground clearance41 cmReference
Claas Axos 310 CX Height
ROPS257 cmReference
ROPS191 cmReference
Cab242 cmReference
Cab257 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
