Tractor · 2008Unverified
Claas Axos 330 CL
Claas Axos 330 CL — Axos Series · 92 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
92 hp
Hover a source tag to verify
Overview
ManufacturerClaasReference
Utility tractorReference
Built in Le Mans, FranceReference
Four-wheel driveReference
Cab standard with heat and opening rear window. Optional air-conditioning, radio, opening front window, and sunroof. ROPS optional.Reference
Variants
330Cbase modelReference
330CLdeluxreReference
330CXpremiumReference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank145.0 LReference
Engine68.6 kWReference
Perkins 1104D-44TAReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
EmissionsTier 3Reference
Power68.6 kWReference
Rated RPM2200Reference
Torque393.1 NmReference
Torque RPM1500Reference
Oil change500 hReference
Transmission
10-speed power shuttleReference
TransmissionRevershiftReference
Typepower shuttleReference
Gears10 forward and reverseReference
PTO & Hydraulics
Valvesup to 3Reference
Total flow60.2 lpmReference
Rear TypeIIReference
Rear TypeIII/II (optional)Reference
Rear lift (at 24"/610mm)2899 kgReference
Front HitchoptionalReference
Front lift2800 kgReference
Rear PTO Type540/1000Reference
Rear PTO Type540/540E (optional)Reference
Rear PTO Type540/540E/1000 (optional)Reference
Front PTOoptionalReference
Front PTO Type1000Reference
Dimensions
Wheelbase248 cmReference
Front tire13.6R24Reference
Rear tire16.9R34Reference
Ag front13.6R24Reference
Ag rear16.9R34Reference
Length418 cmReference
Ground clearance44 cmReference
Ground clearance46 cmReference
Claas Axos 330 CL Height
ROPS262 cmReference
ROPS196 cmReference
Cab247 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
