Claas Elios 330
Claas Elios 330 — Elios Series · 91 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
91 hp
Weight
3635 kg
Hover a source tag to verify
Overview
DistributorClaasReference
ManufacturerCarraroReference
Utility tractorReference
Built in Rovigo, ItalyReference
Four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Wet disc brakesReference
Trailer brakeshydraulicReference
Cab standard with heat. Optional air-conditioning.Reference
Engine
FPT 3.6L 4-cyl dieselReference
Fuel tank104.8 LReference
Exhaust fluid (DEF)9.8 LReference
Engine (gross)67.9 kWReference
Engine (max)68.6 kWReference
FPTReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.6 LReference
Bore/Stroke102 x 110 mmReference
Rated Power (gross)67.9 kWReference
Maximum Power (gross)68.6 kWReference
Rated RPM2300Reference
Torque366.1 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
30-speed two-speed power shiftReference
Typetwo-speed power shiftReference
Gears30 forward and 15 reverseReference
PTO & Hydraulics
Pressure190.0 barReference
Valves2 or 3Reference
Pump flow60.0 lpmReference
Pump flow87.1 lpmReference
Total flow87.1 lpmReference
Total flow113.9 lpmReference
Steering flow26.9 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)2330 kgReference
Front HitchIIReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
Wheelbase228 cmReference
Weight3635 kgReference
Length404 cmReference
Width164 cmReference
Height (cab)262 cmReference
Max weight5200 kgReference
Clearance (front axle)34 cmReference
Clearance (rear axle)46 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
