Tractor · 2004Unverified
Claas Nectis 227
Claas Nectis 227 — Nectis Series · 68 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
68 hp
Weight
5777 to 6108 pounds
Hover a source tag to verify
Overview
ManufacturerClaasReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringhydrostatic powerReference
Wet disc brakesReference
optionalReference
Engine
3.4L 3-cylReference
Fuel tank68.1 LReference
Engine50.7 kWReference
NEF F4CE0354CReference
turboReference
3-cylinderReference
Displacement3.4 LReference
Bore/Stroke104 x 132 mmReference
Power50.7 kWReference
Rated RPM2300Reference
Torque267.0 NmReference
Torque RPM1400Reference
Transmission
12-speedReference
24-speedReference
Gears12 forward and reverseReference
Gears24 forward and reverseReference
PTO & Hydraulics
Total flow48.1 lpmReference
Rear lift3140 kgReference
Rear PTO Type540/750/groundReference
Dimensions
Wheelbase207 cmReference
Weight5777 to 6108 poundsReference
Front tire6.00-16Reference
Rear tire12.4R28Reference
Ag front6.00-16Reference
Ag rear12.4R28Reference
Ag front7.50-16Reference
Length402 cmReference
Height234 cmReference
Weight2620 kgReference
Weight2770 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
