Tractor · 2023Unverified
Claas Nexos 220
Claas Nexos 220 — Nexos Series · 85 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
85 hp
Weight
6128.84 to 7572.87 pounds
Hover a source tag to verify
Overview
DistributorClaasReference
ManufacturerCarraroReference
Orchard/Vineyard tractorReference
Built in Rovigo, ItalyReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab or two-post mid-mount folding ROPS.Reference
Engine
FPT 3.6L 4-cyl dieselReference
Fuel tank74.9 LReference
Fuel tank99.9 LReference
Exhaust fluid (DEF)9.8 LReference
Engine (max)63.4 kWReference
FPTReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.6 LReference
Bore/Stroke102 x 110 mmReference
Maximum Power (gross)63.4 kWReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
24-speed mechanical shuttleReference
15-speed mechanical shuttleReference
30-speed mechanical shuttleReference
30-speed two-speed power shiftReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Gears24 forward and reverseReference
Gears15 forward and reverseReference
Gears30 forward and reverseReference
Typetwo-speed power shiftReference
Gears30 forward and 15 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure190.0 barReference
Valves2 to 4Reference
Pump flow57.2 lpmReference
Pump flow82.1 lpmReference
Steering flow25.0 lpmReference
Rear TypeIIReference
Front HitchIIReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
S Wheelbase217 cmReference
MD Wheelbase211 cmReference
M Wheelbase217 cmReference
LD Wheelbase210 cmReference
L Wheelbase215 cmReference
XL Wheelbase215 cmReference
Weight6128.84 to 7572.87 poundsReference
Length403 cmReference
LD ROPS Length399 cmReference
MD ROPS Length399 cmReference
S Width99 cmReference
MD Width107 cmReference
M Width119 cmReference
LD Width107 cmReference
L Width127 cmReference
XL Width127 cmReference
S 2WD Clearance (front axle)30 cmReference
S 4WD Clearance (front axle)21 cmReference
MD Clearance (front axle)31 cmReference
M Clearance (front axle)22 cmReference
LD Clearance (front axle)31 cmReference
L ROPS Clearance (front axle)37 cmReference
L Cab Clearance (front axle)22 cmReference
XL ROPS Clearance (front axle)37 cmReference
XL Cab Clearance (front axle)22 cmReference
S 2WD Front tread89 to 119 cmReference
S 4WD Front tread98 cmReference
M Front tread110 cmReference
MD Front tread127 cmReference
L Front tread137 cmReference
XL Front tread141 cmReference
LD Front tread148 cmReference
S 2WD3050 kgReference
S 4WD3200 kgReference
MD2780 kgReference
M3285 kgReference
LD2840 kgReference
L ROPS2885 kgReference
L Cab3345 kgReference
XL ROPS2975 kgReference
XL Cab3435 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Capacities
S 2WD Max capacity4199 kgReference
S 4WD Max capacity4500 kgReference
MD Max capacity4199 kgReference
M Max capacity4799 kgReference
LD Max capacity4199 kgReference
L ROPS Max capacity4399 kgReference
L Cab Max capacity4799 kgReference
XL ROPS Max capacity4399 kgReference
XL Cab Max capacity4799 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
