Tractor · 2013Unverified

Claas Talos 120

Name: Claas Talos 120
Brand: Claas

Claas Talos 120 — Talos Series · 47 hp. Reference specifications; pending source verification.

The Claas Talos 120 is a tractor model with a power output of 47 hp, making it one of the more compact options in its class. It was produced from 2013 to 2023. The vehicle features a 4-cylinder diesel liquid-cooled engine, driving through four-wheel drive via a 16-speed gearbox. Its listed operating weight ranges from 4420 to 4861 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

47 hp

Max power

46.9 hp

Weight

4420 to 4861 pounds

Catalogue coverage

Variants represented

Richest spec table

65 rows

Recorded power

47 hp

Transmissions

16-speed synchromesh

Production years

2013-2023

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorClaasReference

ManufacturerLSReference

Utility tractorReference

Four-wheel driveReference

Differential lockelectro-hydraulic rearReference

Power steeringReference

Two-post folding ROPS. Cab available with air-conditioning.Reference

Variants

U5020similar LS modelReference

Engine

LS 2.5L 4-cyl dieselReference

Fuel tank60.2 LReference

Engine35.0 kWReference

LSReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.5 LReference

Bore/Stroke88 x 103 mmReference

EmissionsTier IIIReference

Power35.0 kWReference

Rated RPM2600Reference

Torque143.1 NmReference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders4 cylinderReference

Rated engine speed2,300 rpmReference

Emissions complianceTier IIIReference

Engine torque at rated speed47.9 kgReference

Bore and stroke3.46x4.06 inchesReference

Cooling systemliquid-cooledReference

Transmission

16-speed synchromeshReference

TypesynchromeshReference

Gears16 forward and reverseReference

Transmission TypeSync ShuttleReference

forward and reverse optionsSynchromesh; 16 F & RReference

Wheel Drive4WDReference

PTO & Hydraulics

Valves2 to 4Reference

Pump flow36.0 lpmReference

Rear lift1850 kgReference

Rear PTOindependentReference

Rear PTO Type540/540E/1000Reference

Dimensions

Wheelbase204 cmReference

Weight4420 to 4861 poundsReference

Length356 cmReference

Height (ROPS)256 cmReference

Height (cab)241 cmReference

ROPS2004 kgReference

Cab2204 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

Capacities

Max capacity5499 kgReference

Capacity152.6 ciReference

General

Make & ModelLSReference

Rollover protective structureTwo-post folding ROPSReference

Power

Max Power46.9 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Hydraulics

Remote Valves2 to 4 valvesReference

Rear Hitch maximum lift capacity1,850.2 kgReference

Dimensions & weight

Height Over Cab241.3 cmReference

Height Over ROPS256.3 cmReference

Overall Length356.9 cmReference

Overall weight2,004.9 kgReference

Operator station

Cab AvailabilityAvailableReference

Steering & brakes

Steering typepowerReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
