The Claas Xerion 2500 is a tractor model with a rated output of 250 hp. It was produced from 1997 to 1999. The Xerion 2500 is powered by a 6-cylinder turbocharged intercooled engine, which drives the four-wheel drive system via a hydrostatic transmission. Its listed weight is 9502 kg, making it suitable for jobs covering approximately 1,500+ acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
250 hp
Weight
9502 kg
Catalogue coverage
Variants represented
2
Richest spec table
29 rows
Recorded power
250 hp
Recorded weight
9502 kg
Transmissions
hydrostatic
Production years
1997-1999
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerClaasReference
Drive4x4 4WDReference
Steeringhydrostatic powerReference
Dry disc brakesReference
standard with A/CReference
Engine
Perkins 8.7L 6-cylReference
Fuel tank459.9 LReference
Engine186.4 kWReference
Perkins 1306Reference
intercooled turboReference
6-cylinderReference
Displacement8.7 LReference
Bore/Stroke117 x 135 mmReference
Power186.4 kWReference
Rated RPM2100Reference
PTO & Hydraulics
Total flow120.0 lpmReference
Rear lift4500 kgReference
Rear lift9598 kgReference
Rear PTO Type1000/1250Reference
Dimensions
Wheelbase290 cmReference
Weight9502 kgReference
Front tire650/75R32Reference
Rear tire650/75R32Reference
Ag front650/75R32Reference
Ag rear650/75R32Reference
Length629 cmReference
Height350 cmReference
Transmission
TransmissionhydrostaticReference
Gearsinfinite forward and reverseReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
