The Claas Xerion 3000 is a tractor with a rated power output of 300 hp, positioning it at the higher end of its class in terms of power. It was manufactured from 1997 to 1999. The Xerion 3000 is equipped with a 6-cylinder turbocharged intercooled engine and four-wheel drive, paired with a hydrostatic transmission. It has an operating weight of 9502 kg and is suited to operations spanning 1,500+ acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
300 hp
Weight
9502 kg
Catalogue coverage
Variants represented
2
Richest spec table
29 rows
Recorded power
300 hp
Recorded weight
9502 kg
Transmissions
hydrostatic
Production years
1997-1999
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerClaasReference
Drive4x4 4WDReference
Steeringhydrostatic powerReference
Dry disc brakesReference
standard with A/CReference
Engine
Perkins 8.7L 6-cylReference
Fuel tank459.9 LReference
Engine223.7 kWReference
Perkins 1306Reference
intercooled turboReference
6-cylinderReference
Displacement8.7 LReference
Bore/Stroke117 x 135 mmReference
Power223.7 kWReference
Rated RPM2100Reference
PTO & Hydraulics
Total flow120.0 lpmReference
Rear lift4500 kgReference
Rear lift9598 kgReference
Rear PTO Type1000/1250Reference
Dimensions
Wheelbase290 cmReference
Weight9502 kgReference
Front tire650/75R32Reference
Rear tire650/75R32Reference
Ag front650/75R32Reference
Ag rear650/75R32Reference
Length629 cmReference
Height350 cmReference
Transmission
TransmissionhydrostaticReference
Gearsinfinite forward and reverseReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
