Tractor · 2004Unverified
Claas Xerion 3300 Saddle Trac
Claas Xerion 3300 Saddle Trac — Xerion Series · 335 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
335 hp
Hover a source tag to verify
Overview
ManufacturerClaasReference
Four-wheel Drive (4WD) tractorReference
Drive4x4 4WDReference
Differential lockelectro-hydraulicReference
Steeringfour-wheel steeringReference
Integrated hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
Traccenter cabinReference
Saddle Tracfront cabReference
Trac VCpivoting cabinReference
Engine
Caterpillar 8.8L 6-cyl dieselReference
Engine249.8 kWReference
CaterpillarReference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.8 LReference
EmissionsTier 3aReference
Power249.8 kWReference
Rated RPM2100Reference
Torque1499.7 NmReference
Torque RPM1500Reference
Transmission
continuously variable transmissionReference
TransmissionZF Eccom 3.5 CVTReference
Typecontinuously variable transmissionReference
Gearsinfinite forward and reverseReference
Capacities
Fuel620.0 LReference
PTO & Hydraulics
Hydraulic system130.0 LReference
Typeload sensingReference
Capacity130.0 LReference
Pressure200.0 barReference
Pressure260.0 barReference
Valvesup to 5Reference
Pump flow110.1 lpmReference
Pump flow235.0 lpmReference
Total flow190.0 lpmReference
Rear TypeIIIReference
Rear lift11725 kgReference
Front HitchIIIReference
Front lift7139 kgReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Dimensions
Wheelbase329 cmReference
Length662 cmReference
Width248 cmReference
Height (cab)392 cmReference
Max weight32999 kgReference
Ground clearance46 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
