Tractor · 2014Unverified

Claas Xerion 4000

Name: Claas Xerion 4000
Brand: Claas

Claas Xerion 4000 — Xerion Series · 419 hp. Reference specifications; pending source verification.

The Claas Xerion 4000 is a tractor model rated at approximately 419 horsepower, making it a powerful model within its class. It was produced from 2014 to 2019. This model features a 6-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a continuously variable transmission, and has a listed operating weight of 16,170 kg. It is suitable for large-scale operations of over 1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

419 hp

Max power

435 hp

Weight

16170 kg

Catalogue coverage

Variants represented

Richest spec table

84 rows

Recorded power

419 hp

Recorded weight

16170 kg

Transmissions

hydro-mechanical CVT

Production years

2014-2019

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerClaasReference

Four-wheel Drive (4WD) tractorReference

Drive4x4 4WDReference

Differential lockelecto-hydraulic front and rearReference

Hydraulic wet disc brakesReference

Variants

Traccenter cabinReference

Saddle Tracfront cabReference

Trac VCpivoting cabinReference

Engine

Mercedes-Benz 10.6L 6-cyl dieselReference

Engine (gross)312.4 kWReference

Engine (max)324.4 kWReference

Mercedes-Benz OM 470 LAReference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement10.6 LReference

Bore/Stroke125 x 145 mmReference

EmissionsStage IVReference

Rated Power (gross)312.4 kWReference

Maximum Power (gross)324.4 kWReference

Rated RPM1900Reference

Idle RPM800-1976Reference

Torque2100.4 NmReference

Torque RPM1300Reference

Starter typeelectricReference

Fuel TypedieselReference

No of Cylinders6 cylinderReference

Rated engine speed1,900 RPMReference

Emissions complianceStage IVReference

Engine torque at rated speed702.6 kgReference

Bore and stroke4.92x5.71 inchesReference

Cooling systemliquid-cooledReference

Transmission

hydro-mechanical CVTReference

TransmissionZF Eccom 4.5Reference

Typehydro-mechanical CVTReference

Gearsinfinite forward and reverseReference

Transmission TypeCVTReference

forward and reverse optionsHydro-Mechanical CVT : infinite forward and reverseReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)283.4 kWReference

Hydraulic system120.0 LReference

Capacity120.0 LReference

Pressure200.0 barReference

Rear valvesup to 7Reference

Front valvesup to 3Reference

SCV flow104.8 lpmReference

Total flow194.9 lpmReference

Rear TypeIVNReference

Rear lift10196 kgReference

Front HitchIIINReference

Front lift8260 kgReference

Rear PTOindependentReference

Rear PTO Type1000 (1.75)Reference

Rear PTO Type1000 (2.25)Reference

Capacities

Fuel740.0 LReference

Fuel930.0 LReference

Exhaust fluid (DEF)90.1 LReference

Fuel tank930.1 LReference

Diesel exhaust fluid (DEF) tank90.1 LReference

Dimensions

Wheelbase359 cmReference

Weight16170 kgReference

Length759 cmReference

Width248 cmReference

Height394 cmReference

Electrical

GroundnegativeReference

General

Make & ModelClaasReference

Cruise controlAvailableReference

Power

Max Power435 hpReference

Rated Power419 hpReference

PTO

PTO Power380 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Steering & brakes

Brakeshydraulic wet discReference

Hydraulics

Pump Rated Output (total)51.5 gpmReference

Maximum operating pressure2,900 psiReference

Remote Valvesup to 7 ValvesReference

Rear Hitch category (SAE designation)Category IVNReference

Rear Hitch maximum lift capacity10,196.7 kgReference

Front Hitch category (SAE designation)Category IIINReference

Dimensions & weight

Overall Height394.2 cmReference

Overall Length759.2 cmReference

Overall Width248.9 cmReference

Overall weight16,170.6 kgReference

Operator station

Cab AvailabilityTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
