Tractor · 1933Unverified
Cletrac 80D
Cletrac 80D — Agricultural Crawler tractor · 86 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
86 hp
Max power
64.3 kW
Weight
10886 kg
Hover a source tag to verify
Overview
ManufacturerCletracReference
Agricultural Crawler tractorReference
Built in Cleveland, Ohio, USAReference
DrivecrawlerReference
Open operator station.Reference
Engine
Hercules 11.6L 6-cyl dieselReference
Drawbar (tested)64.3 kWReference
Belt (tested)75.0 kWReference
Hercules DHXReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement11.6 LReference
Bore/Stroke127 x 152 mmReference
Rated RPM1300Reference
Starter typeelectricReference
Belt power (max)75.0 kWReference
Max power64.3 kWReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
ClutchdryReference
Dimensions
Weight10886 kgReference
17-inch tracksReference
Length439 cmReference
Width240 cmReference
Height212 cmReference
Ground clearance40 cmReference
Gauge170 cmReference
80D Serial Numbers
19336000Reference
19346070Reference
19356154Reference
19366316Reference
Final6321Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter60 cmReference
Width38 cmReference
RPM535Reference
Speed1021.08 meters/minReference
Cletrac 80D Tracks
Width43 cmReference
Test results
Diesel 3-speed crawlerJune 15 - July 17, 1936Link: Nebraska Tractor Test 263 fileReference
Drawbar performanceReference
Gear 1 used for power test.Reference
Max pull8687 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
