Tractor · 1936Unverified
Cletrac AG
Cletrac AG — Agricultural Crawler tractor · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Max power
18.2 kW
Weight
3084 kg
Hover a source tag to verify
Overview
ManufacturerCletracReference
Agricultural Crawler tractorReference
Built in Cleveland, Ohio, USAReference
DrivecrawlerReference
Steeringmechanical clutchedReference
Open operator station.Reference
Variants
ADdieselReference
AGgasolineReference
AGHhillsideReference
Engine
Herclues 3.7L 4-cyl gasolineReference
Fuel tank68.1 LReference
Plows3 (14-inch)Reference
Drawbar (tested)18.2 kWReference
Belt (tested)22.6 kWReference
HercluesReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement3.7 LReference
Bore/Stroke102 x 114 mmReference
Fuel systemTillotson P1B carburetorReference
Rated RPM1400Reference
Firing order1-2-4-3Reference
Oil capacity12.3 LReference
Coolant capacity15.1 LReference
Sparkplug gap0.635 mmReference
Belt power (max)22.6 kWReference
Max power18.2 kWReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Clutchdry discReference
Dimensions
Weight3084 kgReference
12-inch tracksReference
Length269 cmReference
Width145 cmReference
Height139 cmReference
AG Gauge106 cmReference
AGH Gauge127 cmReference
AG Serial Numbers
193614552Reference
193718422Reference
19382X0202Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter26 cmReference
Width21 cmReference
RPM1275Reference
Speed1066.80 meters/minReference
Cletrac AG Tracks
Width30 cmReference
Width35 cmReference
Width40 cmReference
Test results
Gasoline https://digitalcommons.unl.edu/cgi/viewcontent.cgi?article=1888&context=tractormuseumlit crawlerJune 16 - 26, 1936Reference
Belt fuel use (max)13.2 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull2383 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
