Tractor · 1937Unverified
Cletrac BG
Cletrac BG — Agricultural Crawler tractor · 38 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
38 hp
Max power
21.1 kW
Weight
3980 kg
Hover a source tag to verify
Overview
ManufacturerCletracReference
Agricultural Crawler tractorReference
Built in Cleveland, Ohio, USAReference
DrivecrawlerReference
Open operator station.Reference
Variants
BGgasolineReference
BDdieselReference
BGHhillsideReference
Engine
Hercules 4.6L 6-cyl gasolineReference
Drawbar (claimed)28.3 kWReference
Belt (claimed)37.3 kWReference
Plows4Reference
Drawbar (tested)21.1 kWReference
Belt (tested)29.1 kWReference
HerculesReference
gasolineReference
6-cylinderReference
liquid-cooledReference
Displacement4.6 LReference
Bore/Stroke95 x 108 mmReference
Air cleaneroil bathReference
Rated RPM1400Reference
Starter typeelectricReference
Belt power (max)29.1 kWReference
Max power21.1 kWReference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 2 reverseReference
ClutchdryReference
Dimensions
Weight3980 kgReference
14-inch tracksReference
Length295 cmReference
Width152 cmReference
Height149 cmReference
BG Gauge111 cmReference
BGH Gauge132 cmReference
BG Serial Numbers
19372C000Reference
19382C452Reference
19392C578Reference
19402C780Reference
19412C338Reference
19422C654Reference
19432C738Reference
1944-----Reference
19456C0000Reference
19468C370Reference
19479C062Reference
194810C238Reference
194911C458Reference
195011C950Reference
195112C229Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter30 cmReference
Width21 cmReference
RPM1045Reference
Speed1005.84 meters/minReference
Cletrac BG Tracks
Width35 cmReference
Width40 cmReference
Width45 cmReference
Width50 cmReference
Test results
Gasoline crawler 4-speedJune 16 - July 10, 1936Link: Nebraska Tractor Test 259 fileReference
Belt fuel use (max)17.4 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull2781 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
