Tractor · 1937Unverified
Cletrac CG
Cletrac CG — Agricultural Crawler tractor · 53 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
53 hp
Max power
39.2 kW
Weight
5216 kg
Hover a source tag to verify
Overview
ManufacturerCletracReference
Agricultural Crawler tractorReference
DrivecrawlerReference
Open operator station.Reference
Engine
Hercules 6.3L 6-cyl gasolineReference
Belt (claimed)39.2 kWReference
Drawbar (tested)34.1 kWReference
Hercules WXC3Reference
gasolineReference
6-cylinderReference
liquid-cooledReference
Displacement6.3 LReference
Bore/Stroke108 x 114 mmReference
Air cleaneroil bathReference
Rated RPM1565Reference
Starter typeelectricReference
Max power39.2 kWReference
Max power34.1 kWReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (tested)39.2 kWReference
Dimensions
Weight5216 kgReference
13-inch tracksReference
Length322 cmReference
Width170 cmReference
Height161 cmReference
Gauge121 cmReference
CG Serial Numbers
19375M000Reference
19385M190Reference
19395M260Reference
19405M130Reference
19415M544Reference
19425M605Reference
Final5M608Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter33 cmReference
Width27 cmReference
RPM1000Reference
Speed1036.32 meters/minReference
Cletrac CG Tracks
Width33 cmReference
Test results
Gasoline 3-speed crawlerSeptember 16 - October 4, 1937Link: Nebraska Tractor Test 289 fileReference
PTO performanceReference
Fuel use25.0 l/hourReference
Drawbar performanceReference
Max pull4257 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
