Tractor · 1934Unverified
Cletrac E
Cletrac E — Agricultural Crawler tractor · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Max power
15.3 kW
Weight
4950 to 6100 pounds
Hover a source tag to verify
Overview
ManufacturerCletracReference
Agricultural Crawler tractorReference
Built in Cleveland, Ohio, USAReference
DrivecrawlerReference
Final drivesspur gearReference
Open operator station.Reference
Variants
EHercules gas engineReference
EDHercules diesel engineReference
ED2Buda diesel engineReference
Engine
Hercules 3.7L 4-cyl gasolineReference
Fuel tank68.1 LReference
Drawbar (claimed)18.3 kWReference
Belt (claimed)21.6 kWReference
Drawbar (tested)15.3 kWReference
Belt (tested)21.4 kWReference
Hercules OOCReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement3.7 LReference
Bore/Stroke102 x 114 mmReference
Rated RPM1300Reference
Belt power (max)21.4 kWReference
Max power15.3 kWReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear PTOoptionalReference
Rear PTO Type540 (1.375)Reference
Dimensions
Weight4950 to 6100 poundsReference
13-inch tracksReference
Length267 cmReference
Width191 cmReference
Height140 cmReference
Shipping weight2245 kgReference
Operating weight2766 kgReference
Gauge157 cmReference
E Serial Numbers
19341A00Reference
19351A08Reference
19361A80Reference
19373A000Reference
19384A842Reference
19395A072Reference
19405A242Reference
19415A315Reference
Final5A330Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter26 cmReference
Width21 cmReference
RPM1085Reference
Speed909.83 meters/minReference
Cletrac E Tracks
Width33 cmReference
Test results
Gasoline 3-speed crawlerJune 16 - July 9, 1936Link: Nebraska Tractor Test 261 fileReference
Belt fuel use (max)12.5 l/hourReference
Drawbar performanceReference
Max pull1754 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
