Tractor · 1937Unverified
Cletrac ED2
Cletrac ED2 — Agricultural Crawler tractor · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
2630 kg
Hover a source tag to verify
Overview
ManufacturerCletracReference
Agricultural Crawler tractorReference
Built in Cleveland, Ohio, USAReference
DrivecrawlerReference
Open operator station.Reference
Variants
EHercules gas engineReference
EDHercules diesel engineReference
ED2Buda diesel engineReference
EHD2high-clearanceReference
Engine
Buda 3.2L 4-cyl dieselReference
Drawbar (claimed)18.6 kWReference
Belt (claimed)24.6 kWReference
Plows2-3 (14-inch)Reference
Buda 4DT196Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.2 LReference
Bore/Stroke92 x 121 mmReference
Starter typeelectricReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Dimensions
Weight2630 kgReference
8-inch tracksReference
Length267 cmReference
ED2-38 Width120 cmReference
ED2-62 Width199 cmReference
Height (hood)140 cmReference
Gauge96 cmReference
Gauge106 cmReference
Gauge157 cmReference
ED2 Serial Numbers
19371T00 (ED2-62)Reference
19381T14 (ED2-62)Reference
19391T26 (ED2-62)Reference
19401T44 (ED2-62)Reference
Final1T84 (ED2-62)Reference
19371S00 (ED2-38)Reference
19381S10 (ED2-38)Reference
Final1S52 (ED2-38)Reference
19385S00 (ED2-42)Reference
19395S92 (ED2-42)Reference
19406S60 (ED2-42)Reference
19416S72 (ED2-42)Reference
Final6S80 (ED2-42)Reference
FAQ: How to read a serial number table.Reference
Cletrac ED2 Tracks
Width20 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
