The Cletrac FG is a tractor with a rated power output of 94 hp, positioning it within the middle power range of its class. Manufactured from 1938 to 1943, this model features a 6-cylinder diesel liquid-cooled engine, which drives a tracked undercarriage via a 4-speed gearbox. It is suitable for tasks on areas of approximately 200-800 acres in size. Details of UK and US specifications are provided.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
94 hp
Catalogue coverage
Variants represented
2
Richest spec table
31 rows
Recorded power
94 hp
Transmissions
4-speed gear
Production years
1938-1943
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerCletracReference
Agricultural Crawler tractorReference
DrivecrawlerReference
Open operator station.Reference
Variants
FGgasolineReference
FDdieselReference
Engine
Hercules 15.3L 6-cyl gasolineReference
Drawbar (claimed)70.1 kWReference
Belt (claimed)82.8 kWReference
Hercules HXEReference
gasolineReference
6-cylinderReference
liquid-cooledReference
Displacement15.3 LReference
Bore/Stroke146 x 152 mmReference
Rated RPM1120Reference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 2 reverseReference
Dimensions
TracksReference
Length457 cmReference
Width254 cmReference
Height (steering wheel)223 cmReference
Gauge175 cmReference
FG Serial Numbers
19381C000Reference
19391C532Reference
19401C606Reference
19411C796Reference
19421C846Reference
19431C880Reference
FAQ: How to read a serial number table.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
