Tractor · 1936Unverified
CO-OP 2
CO-OP 2 — Row-Crop tractor · 32 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
32 hp
Max power
22.1 kW
Weight
2268 kg
Hover a source tag to verify
Overview
DistributorCO-OPReference
ManufacturerDuplex MachineryReference
Row-Crop tractorReference
Built in Battle Creek, Michigan, USAReference
Two-wheel driveReference
Open operator station.Reference
Engine
Chrysler 3.3L 6-cyl gasolineReference
Fuel tank83.3 LReference
Plows2 (14-inch)Reference
Drawbar (tested)22.1 kWReference
Belt (tested)24.7 kWReference
ChryslerReference
gasolineReference
6-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke79 x 111 mmReference
Rated RPM1500Reference
Coolant capacity17.0 LReference
Belt power (max)24.7 kWReference
Power at rated engine speed23.6 kWReference
Max power22.1 kWReference
Transmission
5-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
PTO (tested)23.6 kWReference
Dimensions
Weight2268 kgReference
Front tire6.00-16Reference
Rear tire11.25-28Reference
Ag front6.00-16Reference
Ag rear11.25-28Reference
Length316 cmReference
Width194 cmReference
Height146 cmReference
Operating weight2268 kgReference
Test results
Gasoline 5-speed 2WDOctober 22 - November 10, 1936Link: Nebraska Tractor Test 275 fileReference
Belt fuel use (max)13.2 l/hourReference
PTO performanceReference
Fuel use11.0 l/hourReference
Drawbar performanceReference
Gear 3 used for power test.Reference
Max pull898 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
