Tractor · 1964Unverified
Cockshutt 1850
Cockshutt 1850 — Row-Crop tractor · 93 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
93 hp
Max power
62.3 kW
Weight
8965 to 10965 pounds
Hover a source tag to verify
Overview
ManufacturerCockshuttReference
Row-Crop tractorReference
Original price was $8,500 in 1969Reference
Two- or four-wheel driveReference
Steeringpower assistReference
Differential disc brakesReference
Open operator station. Oliver Continental Cab optional with available air-conditioning.Reference
Engine
Waukesha-Oliver 5.1L 6-cyl gasolineReference
Perkins 5.8L 6-cyl dieselReference
Waukesha-Oliver 5.1L 6-cyl LP GasReference
Drawbar (tested)63.0 kWReference
Waukesha-OliverReference
gasolineReference
6-cylinderReference
liquid-cooledReference
Displacement5.1 LReference
Bore/Stroke98 x 111 mmReference
Air cleanerdry with precleanerReference
Compression8.5:1Reference
Rated RPM2400Reference
Starter volts12Reference
Oil capacity7.6 LReference
Coolant capacity18.9 LReference
PerkinsReference
dieselReference
The 354 Perkins diesel in the Oliver 1850 was initially listed as a 352.Reference
Displacement5.8 LReference
Bore/Stroke99 x 127 mmReference
Air cleanerdry with pre-cleanerReference
Compression16:1Reference
Oil capacity11.4 LReference
LP GasReference
Compression9:1Reference
Power at rated engine speed69.3 kWReference
Max power62.3 kWReference
Power at rated engine speed69.3 kWReference
Max power59.7 kWReference
Power at rated engine speed68.9 kWReference
Max power57.2 kWReference
Max power63.0 kWReference
Transmission
6-speed unsynchronizedReference
12-speed partial powershiftReference
18-speed partial power shiftReference
TypeunsynchronizedReference
Gears6 forward and 2 reverseReference
Clutch330mm dry discReference
Oil capacity40.7 LReference
TransmissionHydra-PowerReference
Typepartial powershiftReference
Gears12 forward and 4 reverseReference
TransmissionHydraul-ShiftReference
Typepartial power shiftReference
Gears18 forward and 6 reverseReference
Introduced in late 1967, the Hydraul-Shift transmission provided an on-the-move shift to underdrive and overdrive.Reference
PTO & Hydraulics
Gas PTO (claimed)68.6 kWReference
Diesel PTO (claimed)68.6 kWReference
LP-gas PTO (claimed)67.1 kWReference
PTO (tested)69.3 kWReference
Hydraulic system18.9 LReference
Typeopen centerReference
Capacity18.9 LReference
Pressure172.4 barReference
Valves2 to 4Reference
Pump flow60.2 lpmReference
Rear TypeIIReference
Rear TypeIIIReference
Rear lift (at 24"/610mm)2721 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type1000Reference
Rear PTO Type540/1000Reference
Capacities
Gas Fuel130.6 LReference
Diesel Fuel119.2 LReference
LP-gas Fuel159.0 LReference
LP-gas Fuel295.2 LReference
Dimensions
2WD Wheelbase261 cmReference
4WD Wheelbase219 cmReference
Weight8965 to 10965 poundsReference
Front tire7.50-15Reference
Rear tire18.4-34Reference
2WD Ag front7.50-15Reference
4WD Ag front12.4/11-24Reference
Ag rear18.4-34Reference
2WD Ag front7.50-18Reference
4WD Ag front13.6/12-24Reference
2WD Ag rear15.5-38Reference
4WD Ag rear23.1-30Reference
4WD Ag rear23.1-34Reference
2WD Length405 cmReference
4WD Length387 cmReference
Width219 cmReference
Height (steering wheel)199 cmReference
Ground clearance64 cmReference
2WD Front tread23/36 cmReference
2WD Front tread172 to 227 cmReference
4WD Front tread167/179/203 cmReference
Rear tread172 to 227 cmReference
Operating4066 kgReference
Operating4202 kgReference
Operating4810 kgReference
Operating4973 kgReference
Ballasted7359 kgReference
Cockshutt 1850 attachments
front-end loaderReference
1850 Serial Number Location
Serial number plate below the tractor's instrument panel.Reference
1850 Serial Numbers
1964150421Reference
1965153014Reference
1966168127Reference
1967183382Reference
1968200360Reference
1969212673Reference
FAQ: How to read a serial number table.Reference
Attachment overview
Oliver 1610 loaderReference
Oliver 1810 loaderReference
Test results
NTTL 869: diesel 12-speed 4WDReference
NTTL 870: diesel 12-speed 2WDReference
NTTL 875: gasoline 12-speed 2WDReference
NTTL 876: gasoline 12-speed 4WDReference
Diesel 12-speed 4WDOctober 26 - November 3, 1964Link: Nebraska Tractor Test 869 fileReference
PTO performanceReference
Fuel use23.8 l/hourReference
Drawbar performanceReference
Gear 4-low used for power test.Reference
Max pull6535 kgReference
Gear 1-high used for pull test.Reference
Diesel 12-speed 2WDOctober 26 - November 5, 1964Link: Nebraska Tractor Test 870 fileReference
Fuel use23.1 l/hourReference
Max pull4886 kgReference
Gear 2-low used for pull test.Reference
Gasoline 12-speed 2WDNovember 12 - 24, 1964Link: Nebraska Tractor Test 875 fileReference
Fuel use29.1 l/hourReference
Fuel use29.5 l/hourReference
Max pull4842 kgReference
Gear 4-low used for pull test.Reference
Gasoline 12-speed 4WDNovember 16 - 24, 1964Link: Nebraska Tractor Test 876 fileReference
Fuel use30.7 l/hourReference
Fuel use31.0 l/hourReference
Max pull6453 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
