Tractor · 1961Unverified
Cockshutt 570 Super
Cockshutt 570 Super — 500 Series · 60 hp. Reference specifications; pending source verification.
The Cockshutt 570 Super is a tractor with a rated output of 60 hp — making it one of the more compact options in its class. It was produced from 1961 to 1962. It is powered by a 6-cylinder diesel liquid-cooled engine, driving through two-wheel drive with a 6-speed gearbox. It is aimed at jobs of around up to 200 ac. Recorded specifications in UK and US units are listed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
60 hp
Catalogue coverage
Variants represented
2
Richest spec table
22 rows
Recorded power
60 hp
Transmissions
6-speed unsynchronized gear
Production years
1961-1962
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerCockshuttReference
Built in Brantford, Ontario, CanadaReference
Total built1,682Reference
Two-wheel driveReference
Open operator station.Reference
Engine
Hercules 5.6L 6-cyl dieselReference
Drawbar (claimed)44.7 kWReference
Belt (claimed)47.7 kWReference
Plows5Reference
Hercules DD339Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.6 LReference
Transmission
6-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears6 forward and 2 reverseReference
Dimensions
Rear tire14-34Reference
Ag rear14-34Reference
570 Super Serial Numbers
1961DP1001Reference
1962DR1001Reference
FAQ: How to read a serial number table.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
