Tractor · 1937Unverified
Cockshutt 80 Standard
Cockshutt 80 Standard — Standard-tread tractor · 36 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
36 hp
Max power
21.3 kW
Weight
2177 kg
Hover a source tag to verify
Overview
DistributorCockshuttReference
ManufacturerOliverReference
Standard-tread tractorReference
Built in Charles City, Iowa, USAReference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Variants
Row-crop 80tricycle-frontReference
Standard 80fixed-treadReference
Engine
Waukesha-Oliver 5.5L 4-cyl keroseneReference
Waukesha-Oliver 4.9L 4-cyl gasolineReference
Fuel tank49.2 LReference
Fuel tank64.3 LReference
Plows3Reference
Drawbar (tested)26.8 kWReference
Belt (tested)30.8 kWReference
Waukesha-OliverReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement5.5 LReference
Bore/Stroke114 x 133 mmReference
Air cleaneroil bathReference
Rated RPM1200Reference
Starter typehand-crankReference
Starter typeelectric (optional)Reference
gasolineReference
Displacement4.9 LReference
Bore/Stroke108 x 133 mmReference
Belt power (max)29.3 kWReference
Max power21.3 kWReference
Belt power (max)30.8 kWReference
Max power26.8 kWReference
Transmission
3-speed gearReference
4-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Clutchdry discReference
Gears4 forward and 1 reverseReference
The four-speed transmission was added to the Standard 80 in 1938.Reference
Dimensions
Weight2177 kgReference
Front tire7.50-18Reference
Rear tire11.25-24Reference
Ag front7.50-18Reference
Ag rear11.25-24Reference
Ag rear12.75-24Reference
Ballasted weight3628 kgReference
Front tread120 cmReference
Rear tread137 cmReference
80 Standard Serial Number Location
Serial number plate on the left side of the Cockshutt 80 engine.Reference
80 Standard Serial Numbers
1937803929Reference
1938803991Reference
1939805377Reference
1940806880Reference
1941808125Reference
1942809051Reference
1943809991Reference
1944810470Reference
1945811991Reference
1946813067Reference
1947814564Reference
1948815216Reference
FAQ: How to read a serial number table.Reference
Test results
NTTL 301: kerosene 3-speed 2WDReference
NTTL 301: gasoline 3-speed 2WDReference
Kerosene 3-speed 2WDMay 16, 1938 - May 28, 1936Link: Nebraska Tractor Test 301 fileReference
Belt fuel use (max)18.2 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull1631 kgReference
Gear 1 used for pull test.Reference
Gasoline 3-speed 2WDNovember 4 - 8, 1940Link: Nebraska Tractor Test 301 fileReference
Belt fuel use (max)14.4 l/hourReference
Max pull2303 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
