Tractor · 1971Unverified
County 1164
County 1164 · 96 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
96 hp
Weight
8955 to 12825 pounds
Hover a source tag to verify
Overview
ManufacturerCountyReference
Built in Fleet, EnglandReference
The County 1164 was based on the gearbox and transmission from the Ford 5000 and the engine from the Ford 8000.Reference
Drive4x4 4WDReference
Final drivesplanetaryReference
Differential lockmechanical front and rearReference
Power steeringReference
Wet disc brakesReference
Cab standard, optional open platform.Reference
Engine
Ford 6.6L 6-cyl dieselReference
Fuel tank132.5 LReference
Engine86.5 kWReference
Ford 401SReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke112 x 112 mmReference
Power86.5 kWReference
Compression16.5:1Reference
Rated RPM2300Reference
Torque396.0 NmReference
Torque RPM1500Reference
Firing order1-5-3-6-2-4Reference
Starter volts12Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)71.6 kWReference
Typeopen centerReference
Pressure172.4 barReference
Pump flow23.8 lpmReference
Rear TypeIIReference
Controltop-link draft sensingReference
Rear lift1750 kgReference
Rear lift25380 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1900Reference
Engine RPM1000@2060Reference
Dimensions
Wheelbase181 cmReference
Weight8955 to 12825 poundsReference
Front tire16.9-30Reference
Rear tire16.9-30Reference
Ag front16.9-30Reference
Ag rear16.9-30Reference
Ag front18.4x30Reference
Ag front16.9x34Reference
Ag front13.6/12x38Reference
Ag rear18.4x30Reference
Ag rear16.9x34Reference
Ag rear13.6/12x38Reference
Length430 cmReference
Height (steering wheel)177 cmReference
Shipping weight4061 kgReference
Operating weight5817 kgReference
Ground clearance39 cmReference
Front tread172 to 213 cmReference
Rear tread172 to 213 cmReference
Electrical
Charging systemgeneratorReference
Charging amps22Reference
Battery volts12Reference
Battery AH128Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
