Tractor · 1977Unverified
County 1174
County 1174 — Four-wheel Drive (4WD) tractor · 112 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
112 hp
Hover a source tag to verify
Overview
ManufacturerCountyReference
Four-wheel Drive (4WD) tractorReference
Built in Fleet, EnglandReference
Four-wheel driveReference
Final drivesplanetaryReference
Power steeringReference
Disc brakesReference
Cab standard.Reference
Variants
FC 1174forward-controlReference
Engine
Ford 6.6L 6-cyl dieselReference
Fuel tank227.1 LReference
Engine (gross)83.5 kWReference
Engine (net)79.0 kWReference
FordReference
dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement6.6 LReference
Bore/Stroke112 x 112 mmReference
Power (net)79.0 kWReference
Power (gross)83.5 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression16.5:1Reference
Rated RPM2200Reference
Torque374.3 NmReference
Torque RPM1400Reference
StarterelectircReference
Starter volts12Reference
Oil capacity17.0 LReference
Coolant capacity18.8 LReference
Transmission
16-speed two-speed power shiftReference
TransmissionFord Dual PowerReference
Typetwo-speed power shiftReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)63.4 kWReference
PTO (claimed)74.6 kWReference
Typeopen centerReference
Pressure172.4 barReference
Pump flow35.0 lpmReference
Steering flow16.3 lpmReference
Steering press.75.8 barReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type1000 (1.375)Reference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1900Reference
Engine RPM1000@2060Reference
Dimensions
Wheelbase202 cmReference
FC Length492 cmReference
Height (cab)281 cmReference
Electrical
Charging systemalternatorReference
Charging amps46Reference
Battery volts12Reference
Speeds
With 16.9/14-34 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
